12
Be sure to confi gure the following three
settings before use.
Charging the Battery Pack
1 Set the power/mode switch to OFF.
Slide while pressing down the lock button.
MODE
OFF
(CHARGE)
ON
2 Attach the battery pack.
Slide the battery pack down until it locks in place.
3 Connect the AC adapter.
* If the provided AC adapter is AP-V14E,
connect the power cord to the AC adapter,
and plug the power cord into an AC outlet.
•
You can also connect the AC adapter using
the Everio dock connector. ( pg. 6)
•
The access/charge lamp blinks to indicate
charging has started.
•
When the lamp goes out, charging is
fi nished. Unplug the AC adapter (or
the power cord) from the AC outlet and
disconnect the AC adapter from the camera.
Necessary Settings before Use
MENU
Access/Charge
Lamp
Power/Mode
Switch
Set Lever
Bottom of the Camera
BATT.
DC Connector
AC Adapter
(ex. AP-V17E)*
To AC Outlet
(110V to 240V)
Required charging / recording time
(approx.)
The values within ( ) are the times when the
LED light is on.
Battery pack Charging time
Recording
time
BN-VF808U
(Provided)
1 hr. 30 min.
1 hr. 15 min.
(1 hr. 10 min.)
BN-VF815U 2 hr. 40 min.
2 hr. 30 min.
(2 hr. 25 min.)
BN-VF823U 3 hr. 50 min.
3 hr. 45 min.
(3 hr. 35 min.)
8 To detach the battery pack
Slide and hold BATT. (
step 2), then
remove the battery pack.
8 To check the remaining battery power
See page 14.
NOTES
•
You can also use the camera with just the AC
adapter.
•
Please do not pull or bend the AC adapter plug
and cable. This may damage the AC adapter.
To Next Page
