1-2 (No.YA337)
SPECIFICATION
Design & specifications are subject to change without notice.
Items
Contents
HD-56FH96 HD-61FH96 HD-70FH96
Dimensions ( W × H × D ) 131.8 cm × 96.7 cm × 43.4 cm
(52" × 38-1/8" × 17-1/8")
145.6 cm × 104.3 cm × 46.7 cm
(57-3/8" × 41-1/8" × 18-3/8")
162.6 cm × 116.8 cm × 51.9 cm
(64-1/8" × 46" × 20-1/2")
Mass 43 kg (95 lbs) 47 kg (104 lbs) 72 kg (159 lbs)
TV RF System (Analog
/ Digital)
Analog
Digital
CCIR (M)
ATSC terrestrial / Digital cable
Color System (Analog) NTSC
Stereo System (Analog) BTSC (Multi Channel Sound)
Teletext System (Analog) Closed caption (T1-T4 / CC1-CC4)
TV Receiving Channels
and Frequency
(Analog)
VHF Low
VHF High
UHF
CATV
02ch - 06ch : 54MHz - 88MHz
07ch - 13ch : 174MHz - 216MHz
14ch - 69ch : 470MHz - 806MHz
54MHz - 804MHz
Low Band : 02 - 06
High Band : 07 - 13
Mid Band : 14 - 22
Super Band : 23 - 36
Hyper Band : 37 - 64
Ultra Band : 65 - 94, 100 - 135
Sub Mid Band : 01, 96 - 99
TV / CATV Total Channel 191 Channels
Intermediate Frequen-
cy (Analog)
Video IF
Sound IF
45.75 MHz
41.25 MHz (4.5MHz)
Color Sub Carrier Frequency (Analog) 3.58 MHz
Power Input AC120V, 60Hz
Power Consumption 215W 220W
Projection Source 110W High-pressure mercury lamp
Projection Device D-ILA device (Reflection active matrix type LCD) x 3(R / G /B)
Resolution Total=H:1952 × V:1088 [ Effective =H:1920 × V:1080 ]
Screen Transparent screen (unitized fresnel lens / lenticular lens), aspect ratio 16:9
Screen Size
56" (142cm) Measured diagonally
H:124 cm
×
V:69.7cm
61" (155cm) Measured diagonally
H:135 cm
×
V:76.0cm
70" (178cm) Measured diagonally
H:155.5 cm
×
V:87.2cm
Audio Power Output 10W + 10W
Speaker 10cm round type × 2 (Oblique corn)
Antenna Terminal (VHF/UHF, ATSC / DIGITAL CABLE IN)
F-type connector, 75Ω unbalanced, coaxial × 2
Video / Audio Input
[INPUT-1/2/3/4]
Component Video
[INPUT-1/2]
1125i / 750p
525p / 525i
S-Video
[INPUT-1/3/4]
Video
Audio
RCA pin jack × 6
Y : 1V (p-p) (Sync signal: 0.35V(p-p), 3-value sync.), 75 Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1V (p-p), positive (Negative sync provided), 75 Ω
Pb/Pr : 0.7V(p-p), 75 Ω
Mini-DIN 4 pin × 3
Y: 1V (p-p), positive (Negative sync provided), 75 Ω
C: 0.286V (p-p) (Burst signal), 75 Ω
1V (p-p), positive (Negative sync provided), 75 Ω, RCA pin jack × 4
500mV (rms), high impedance, RCA pin jack × 8
Digital Input Video
Audio
HDMI 2-row 19pin connector × 2
(Digital-input terminal is not compatible with picture signals of personal computer)
Digital: HDMI 2-row 19pin connector × 21
Anarog: 500mV(rms) (-4dBs), high impedance, RCA pin jack × 2
PC (RGB) Input D-sub 3-row 15pin × 1
R/G/B : 0.7V (p-p), 75Ω
HD / VD : 1V (p-p) to 5V (p-p), high impedance
< Available signal >
VGA : 640 pixels × 480 pixels (Horizontal : 31.5kHz / Vertical : 60Hz)
XGA : 1024 pixels × 768 pixels (Horizontal : 48.4kHz / Vertical : 60Hz)
Center Channel Input 500mV(rms) (-4dBs), high impedance, RCA pin jack × 1
Monitor / Recording
Output
S-Video
Video
Audio
Mini-DIN 4pin × 1
Y: 1V (p-p), 75Ω
C: 0.286V(p-p) (burst signal), 75Ω
1V (p-p), 75Ω, RCA pin jack × 1
250mV(rms) (-10dBs), Fs-18dB low impedance, RCA pin jack × 2
Audio Output
Variable
Fix
RCA pin jack × 2
More than 0 to 1000mV (rms) (+2.2dBs)
500mV(rms) (-4dBs), low impedance (1000Hz when modulated 100%)
iLink Input/Output TS In/Out (4-pin, S400) × 2, IEEE1394 compliant DTCP digital copy protection compatible
Digital Audio Optical Output Digital SPDIF × 1
AV COMPULINK lll 3.5mm mini jack × 1
RS-232C D-sub 2-row 9 pin [External control for TV set]
Remote Control Unit RM-C14G (AA/R6 / UM-3 battery × 2)
