JVC HR-S2911U User Manual

2-10
2.3 Mechanism timing chart
REEL LOCK
POLE BASE
TENSION ARM
GUIDE ARM
CAPSTAN BRAKE
TU LEVER
DIRECT GEAR
PINCH
ROLLER
BRAKE
LEVER
TENSION
ARM LEVER
LOCK
FREE
OFF
ON
ON
PLAY
(STOP MODE PRESS UP)
STOP
REV
OFF
OFF
OFF
OFF
ON
OFF
FF/REW
EJECT
PLAY
FOR
SLOW
/STILL
REV
SERCH
/SLOW
/STILL
FF
/REW
STOP
REEL
BRAKE
ON
ON
OFF
ON
ON
OFF
OFF2
OFF1
ON
CLUTCH
DIRECT
Movements of a
CONTROL PLATE
(m/m)
0 5 15 20 25 30 35 40 45 50 5510
CONTROL PLATE
MARK
E P SL R ST B FR
MECHANISM MODE
CONTACT

JVC HR-S2911U Specifications

General

Dimensions	430 x 350 x 100 mm
Weight	6.4 lbs
Number of Heads	4
Remote Control	Yes
Tuner	Yes
Type	VCR
Video Format	VHS
Connections	Audio
Playback Speeds	SP, LP
Inputs	Composite video, Audio (RCA), RF
Outputs	Composite video, Audio (RCA)
