No. 51809
HV-L34PRO
22
VSM PRESET SETTING
Item
Measuring
instrument
Test point Adjustment part Description
Setting of
VSM PRESET
Remote
control unit
1.CONT.
2. BRIGHT
3. SHARP
4. COLOUR
5. TINT
1. Select 5.VSM PRESET from the SERVICE MENU.
2. Select STD with the PICTURE MODE key of the remote control
unit.
3. Adjust the function UP/DOWN and LEFT/RIGHT key to bring
the set values of 1.CONT
～
5. TINT to the values shown in
the table.
4. Press the MENU/OK key and memorize the set value.
5. Respectively select the VSM PRESET mode for REGULAR
and BRIGHT, and make similar adjustment as in 3 above.
6. Press the MENU/OK key and memorize the set value.
#
Refer to OPERATING INSTRUCTIONS for the PICTURE
MODE.
Setting item
VSM preset mode
1. CONT. 2. BRIGHT 3. SHARP 4. COLOUR 5. TINT
BRIGHT
+16 0 -10 +3 0
STANDARD
+7 0 -10 0 0
SOFT
00-12-20
SETTING VALUES OF VSM PRESET
To Next Page
