CAUTION: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as
follows:
1. Front: No obstructions and open spacing.
2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions
below.
3. Bottom: Place on a level surface. Maintain an adequate air path for ventilation by placing on
a stand with a height of 10 cm or more.
15 cm
15 cm
10 cm
1 cm1 cm
15 cm
15 cm15 cm
CA-HXGD7
CA-HXGD7
SP-
HXGD7
SP-
HXGD7
Front view
Side view
