JVC HX-Z30 Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 GV10129-002A FRONT PANEL
2 GV40313-001A FELT SPACER (x2)
3 GV40077-002A JVC BADGE
4 GV30417-002A PUNCHING NET
5 GV40382-002A MIRROR SHEET
6 GV20213-001A INNNER LENS
7 GV20208-002A WINDOW SCREEN
8 GV20215-001A ORNAMENT RING
9 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
10 LV40744-001A SOCKET BOLT (x4)
11 GV10132-001A CONTROL BUTTON
12 GV30415-001A FUNCTION BUTTON
13 GV20172-002A PWR/EJCT BTN A
14 GV40381-001A STANDBY INDICAT
15 GV30416-001A FL LENS
16 GV20214-001A FUNCTION LENS
17 QYSDSF2608Z SCREW 2.6mm x 8mm(x9)
18 QYSDSF2608Z SCREW 2.6mm x 8mm
19 QYSDSF2608Z SCREW 2.6mm x 8mm(x7)
20 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
21 QYSDSF2608Z SCREW 2.6mm x 8mm(x7)
22 GV30418-002A STAY BRACKET
23 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
24 E65923-003 TAPPING SCREW
25 GV30434-001A MECHA BRACKET
26 QYSSST3006Z SCREW 3mm x 6mm(x2)
27 GV40121-004A SPACER (x6)
28 GV40418-002A SPACER
29 GV30488-001A FRONT BRACKET
30 QYSDSF2608Z SCREW 2.6mm x 8mm(x3)
31 QYSDSF2608Z SCREW 2.6mm x 8mm
32 GV30310-001A CASS.HOLD.ASSY.
33 GV30311-002A EJECT SYS.ASSY.
34 GV40034-001A DAMPER ASSY.
35 VKY4180-401 CASSETTE SPRING (x2)
36 GV40398-001A SPRING
37 E310243-002 PLASTIC RIVET (x2)
38 VKL7850-002 EJECT SAFTY(R)
39 VKW5258-003 TORSION SPRING
40 QYSBSF3012Z TAP SCREW 3.0mm x 12mm(x2)
41 QYSBSF3010Z TAP SCREW 3mm x 10mm(x2)
42 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
43 QAU0307-001 TUNER ASSY.
44 E310243-002 PLASTIC RIVET
45 GV10111-002A CHASSIS BASE
46 GV40313-002A FELT SPACER (x2)
47 GV30420-005A HEAT SINK
48 GV30281-001A BASE BRACKET
49 QYSBSG3020E TAP SCREW 3mm x 20mm(x4)
50 GV40297-002A LEAF SPRING
51 QYSBSG3014E TAP SCREW 3mm x 14mm
52 QYSBSG3014E TAP SCREW 3mm x 14mm
53 QYSDSTL4008Z ASSY SCREW 4mm x 8mm(x4)
54 QYSBSFG3016Z SCREW 3mm x 16mm
55 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
56 QYSBSG3014E TAP SCREW 3mm x 14mm(x2)
57 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x2)
58 QZW0033-001 STRAIN RELIEF
59 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x3)
60 GV30286-001A INNER BAR
61 E310243-002 PLASTIC RIVET
62 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
63 GV40222-001A BOTTOM SHEET
64 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x2)
65 GV40300-002A BRACKET
66 GV10131-007A REAR PANEL
67 GV30278-002A FAN BRACKET
68 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
69 GV30498-002A REAR BRACKET
70 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
71 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x3)
72 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
73 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
74 QYSBSGY3010E SPECIAL SCREW 3mm x 10mm(x2)
75 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
76 GV40121-004A SPACER
77 GV40121-006A SPACER
78 QYSBSF3012E SPECIAL SCREW 3mm x 12mm(x2)
79 QYSBSG3010Z TAPPING SCREW 3mm x 10mm(x2)
80 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
81 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
82 GV10110-001A/S/ METAL COVER
83 QYSDSG3006M TAP SCREW 3mm x 6mm(x2)
84 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
85 GV20203-001A CD FITTING (1)
86 GV20204-001A CD FITTING (2)
87 GV20205-001A CD FITTING (3)
88 GV20206-001A CD FITTING (4)
89 GV20207-001A CD FITTING (5)
90 GV30299-004A SOUND MODE KNOB (x2)
91 GV30297-002A VOLUME LENS
92 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
93 GV30262-002A
VOLUME ORNAMENT
94 GV30499-001A VOLUME KNOB
95 GV40186-001A NUT
 96 QQT0394-002 POWER TRANSF T 001
 97 QMPK200-200-JD POWER CORD(EU) 2m BLACK
98 QAR0246-001 FAN
99 QUQH12-1109AJ CARD WIRE
100 QUQH12-0909BJ CARD WIRE
101 QUQH12-1019BJ CARD WIRE
102 QUQH10-1714AJ CARD WIRE
103 QUQH12-2118BJ CARD WIRE
104 QUQH12-1513AJ CARD WIRE
 105 QMF51W2-5R0-J8 FUSE F001 5A AC250V
 106 QMF51W2-2R5-J8 FUSE F003 2.5A AC250V
 107 QMF51W2-6R3-J8 FUSE F101 6.3A AC250V
 108 QMF51W2-6R3-J8 FUSE F102 6.3A AC250V
 109 QMF51W2-3R15-J8 FUSE F103 3.15A AC250V
110 GV20212-002A FL HOLDER
