(No.MA232)1-13
 How to connect the extension cable for adjusting
[For KD-G521 and KD-G527]
Caution:
Be sure to attach the heat sink and rear bracket onto the power amplifier IC and regulator IC respectively, before supply the power.
If voltage is applied without attaching these parts, the power amplifier IC and regulator IC will be destroyed by heat.
Side panel
EXTSH002-22P
Extension cable
Rear bracket
CN501
