JVC KD-AR5500 Service Manual

(No.MA140)1-31
4.2.4 Changer mechanism error display
Symptom
Details Error code
Detailed error code
Tray eject error
1.TRAYINSW TIME OVER
(TRAYINSW:L,TRAYOUTSW:H)
2.TRAYOUTSW TIME OVER
(TRAYINSW:H,TRAYOUTSW:H)
3.TRAYINSW TIME OVER
(TRAYINSW:L,TRAYOUTSW:L)
4.MAGIN SW:L H
03
03
03
03
0011
0012
0013
0014
Tray motor TIME OVER
Tray motor does not operate.
Tray stops.
TRAYINSW NG etc.
Magazine is ejected while Tray is
being ejected.
Tray return error
1.TRAYOUTSW TIME OVER
(TRAYINSW:H,TRAYOUTSW:L)
2.TRAYINSW TIME OVER
(TRAYINSW:H,TRAYOUTSW:H)
3.TRAYIN/OUTSW TIME OVER
(TRAYINSW:L,TRAYOUTSW:L)
4.MAGIN SW:L H
03
03
03
03
0016
0017
0018
0019
Tray motor TIME OVER
Tray motor does not operate.
Tray stops.
TRAYOUTSW NG etc
Magazine is ejected while Tray is
being returned.
Lifter up error
1.WAIT position TIME OVER
2.WAIT position TIME OVER
3.WAIT position TIME OVER
02
02
02
0021
0022
0023
Position motor TIME OVER
Position motor does not operate.
Position is not stable in fine
adjustment mode.
Other condition
Lifter down error
1.WAIT position TIME OVER
2.WAIT position TIME OVER
3.WAIT position TIME OVER
02
02
02
0026
0027
0028
Position motor TIME OVER
Position motor does not operate.
Position is not stable in fine
adjustment mode.
Other condition
Chucking error
1.PLAY position TIME OVER
2.PLAY position TIME OVER
3.PLAY position TIME OVER
02
02
02
0031
0032
0033
Position motor TIME OVER
Position motor does not operate.
Position is not stable in fine
adjustment mode.
Other condition
Unchucking error
1.WAIT position TIME OVER
2.WAIT position TIME OVER
3.WAIT position TIME OVER
02
02
02
0036
0037
0038
Position motor TIME OVER
Position motor does not operate.
Position is not stable in fine
adjustment mode.
Other condition
EJECT error
1.EJECT position TIME OVER
2.EJECT position TIME OVER
3.MAGINSW TIME OVER
02
02
01
0041
0042
0043
EJECT cannot be carried out.
Position motor does not operate.
Improper EJECT position.*
Magazine is not ejected.
Initialize error
1.Mechanism SW NG error
2.Absolute position TIME OVER
03
02
0046
0047
TRAYINSW and TRAYOUTSW are L.
Position is not stable in absolute
position.*
*"Position is not stable in WAIT position," "Position is not stable in PLAY position," and "Position is not stable in
absolute position," and "Improper EJECT position" are all Position Motor TIME OVER.
