Page #50 background imageLoading...
Page #50 background image
3-12
R904 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R905 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R908 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R909 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R910 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R912 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R913 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R918 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R941 NRSA02J-101X MG RESISTOR 100
Ω
1/10W J
R951 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R952 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R953 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R954 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R955 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R956 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R971 NRSA63J-394X MG RESISTOR 390k
Ω
1/16W J
R972 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R973 NRSA63D-563X MG RESISTOR 56k
Ω
1/16W D
R974 NRSA63D-394X MG RESISTOR 390k
Ω
1/16W D
R975 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R976 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R978 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R979 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R991 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1009 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R1401 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R1402 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1404 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R1451 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R1452 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R1453 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R1454 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R1455 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R1456 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R1501 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R1502 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1503 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R1504 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1601 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R1602 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R1603 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R1604 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1605 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1606 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1702 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R1703 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1704 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R1705 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1706 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1722 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R1723 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R1724 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R1725 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1726 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1754 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1774 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1801 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R1901 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R1902 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R1903 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R1904 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1905 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1921 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R1922 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R1923 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R1924 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1925 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2401 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2402 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2404 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R2451 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R2452 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R2453 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R2454 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R2455 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R2456 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R2501 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
Symbol
No.
Part No. Part Name Description Local
R2502 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2503 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2504 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2601 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R2602 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2603 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R2604 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2605 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2606 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2702 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R2703 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2704 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R2705 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2706 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2722 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R2723 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2724 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R2725 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2726 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2754 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2774 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2801 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R2901 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R2902 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R2903 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R2904 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2905 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2921 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R2922 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R2923 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R2924 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2925 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3401 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R3403 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3405 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R3653 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3655 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R3801 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3802 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R3803 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R3804 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R3805 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R3806 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R3807 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3808 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3809 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3810 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3811 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R3901 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R3902 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3922 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R4013 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4014 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4015 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R4017 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4021 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R4023 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4031 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4032 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4033 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4034 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4035 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R4036 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4037 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4038 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4039 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4040 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4041 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4042 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4043 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4067 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4069 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R4070 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R4071 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R4073 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R4100 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
Symbol
No.
Part No. Part Name Description Local
