JVC KD-AR5500 Service Manual

3-13
Switch board
Block No. [0][2]
R4101 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R4102 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R4103 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R4151 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R4152 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R4153 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R4201 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R4202 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R4203 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R4251 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R4252 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R4253 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R7001 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R7101 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R7102 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R7103 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7104 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7105 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R7106 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R7107 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7110 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7111 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R7112 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R7113 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7116 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R7117 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R7118 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R7119 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R7120 NRSA02J-100X MG RESISTOR 10
Ω 1/10W J
R7205 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7501 NRS181J-181X MG RESISTOR 180
Ω 1/8W J
R7504 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R7505 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R9001 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R9002 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R9003 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9051 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R9052 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
AR55
00J
L1 NQL334J-4R7X COIL 4.7uH J
L30 NQR0129-003X FERRITE BESDA
L31 NQL093K-2R2X COIL 2.2uH K
L40 NQR0129-003X FERRITE BESDA
L63 NQL093K-1R8X COIL 1.8uH K
L701 NQL79GM-470X COIL 47uH M
L702 NQL79GM-470X COIL 47uH M
L901 QQR1640-001 CHOKE COIL
L971 NQLB7GM-100X COIL 10uH M
L972 NQL71EM-330X COIL 33uH M
L4001 NQL79GM-470X COIL 47uH M
L7201 NQL79GM-470X COIL 47uH M
CN341 QGA2006C1-04 CONNECTOR W-B (1-4)
CN345 QNN0490-001 PIN JACK
CN351 QNZ0095-001 CONNECTOR
CN381 QGA2501C1-03 CONNECTOR W-B (1-3)
CN701 QGF1041C3-16W CONNECTOR FFC/FPC (1-16)
CN702 QGA2006F1-02 CONNECTOR W-B (1-2)
CN721 QGB2027M5-20S CONNECTOR B-B (1-20)
CN901 QNZ0611-001 16P CONNECTOR
CN991 QGA2501F1-02 CONNECTOR W-B (1-2)
CN992 QJB005-040909 SIN ID C-B WIRE
J1 QAM0556-001 ANT CABLE
PP2 QZW0010-001 STYLE PIN
TU1 QAU0324-002 TUNER PUCK
X1 QAX0781-001Z CRYSTAL 41.600MHz
X701 QAX0782-001Z CRYSTAL 32.000MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
X4001 QAX0763-001Z C RESONATOR 4.19MHz

Symbol
No.
Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC801 MN102H60KDR IC
IC815 SG32M90TFIR3C01 IC
IC821 IC-PST3424U-X IC
IC831 NJU7241F33-X IC
IC841 RPM7338-V4 RM.RECEIVER
Q8001 2SB709A/QR/-X TRANSISTOR
Q8002 2SB709A/QR/-X TRANSISTOR
Q8301 2SD601A/QR/-X TRANSISTOR
Q8701 2SB709A/QR/-X TRANSISTOR
Q8702 2SB709A/QR/-X TRANSISTOR
Q8703 2SD601A/QR/-X TRANSISTOR
Q8704 2SD601A/QR/-X TRANSISTOR
Q8705 UN2111-X TRANSISTOR
Q8751 2SD601A/QR/-X TRANSISTOR
Q8752 2SD601A/QR/-X TRANSISTOR
Q8753 2SD601A/QR/-X TRANSISTOR
Q8754 2SD601A/QR/-X TRANSISTOR
Q8755 2SD601A/QR/-X TRANSISTOR
Q8756 2SD601A/QR/-X TRANSISTOR
Q8757 2SD601A/QR/-X TRANSISTOR
Q8758 2SD601A/QR/-X TRANSISTOR
Q8759 2SD601A/QR/-X TRANSISTOR
Q8760 2SD601A/QR/-X TRANSISTOR
Q8761 2SD601A/QR/-X TRANSISTOR
Q8762 2SD601A/QR/-X TRANSISTOR
Q8763 2SD601A/QR/-X TRANSISTOR
Q8764 2SD601A/QR/-X TRANSISTOR
Q8765 2SD601A/QR/-X TRANSISTOR
Q8766 2SD601A/QR/-X TRANSISTOR
Q8767 2SD601A/QR/-X TRANSISTOR
Q8768 2SD601A/QR/-X TRANSISTOR
Q8770 2SD601A/QR/-X TRANSISTOR
Q8771 2SD601A/QR/-X TRANSISTOR
Q8772 2SD601A/QR/-X TRANSISTOR
Q8773 2SD601A/QR/-X TRANSISTOR
Q8774 2SD601A/QR/-X TRANSISTOR
Q8775 2SD601A/QR/-X TRANSISTOR
Q8776 2SD601A/QR/-X TRANSISTOR
Q8777 2SD601A/QR/-X TRANSISTOR
Q8778 2SD601A/QR/-X TRANSISTOR
Q8779 2SD601A/QR/-X TRANSISTOR
Q8780 2SD601A/QR/-X TRANSISTOR
Q8781 2SD601A/QR/-X TRANSISTOR
D8001 MA152WK-X SI DIODE
D8002 UDZS6.2B-X Z DIODE
D8003 UDZS6.2B-X Z DIODE
D8004 UDZS6.2B-X Z DIODE
D8005 UDZS6.2B-X Z DIODE
D8006 UDZS6.2B-X Z DIODE
D8007 UDZS6.2B-X Z DIODE
D8008 UDZS6.2B-X Z DIODE
D8009 UDZS6.2B-X Z DIODE
D8010 UDZS6.2B-X Z DIODE
D8201 MA111-X SI DIODE
D8203 MA152WA-X DIODE
D8701 UDZS6.2B-X Z DIODE
D8702 UDZS6.2B-X Z DIODE
D8703 UDZS6.2B-X Z DIODE
D8704 UDZS6.2B-X Z DIODE
D8731 NSCM315C/Z/-W LED
D8732 NSCM315C/Z/-W LED
D8733 NSCM315C/Z/-W LED
D8734 NSCM315C/Z/-W LED
D8735 NSCM315C/Z/-W LED
D8751 UDZS6.2B-X Z DIODE
D8752 UDZS6.2B-X Z DIODE
D8753 UDZS6.2B-X Z DIODE
D8754 UDZS6.2B-X Z DIODE
D8755 UDZS6.2B-X Z DIODE
D8756 UDZS6.2B-X Z DIODE
D8757 UDZS6.2B-X Z DIODE
D8758 UDZS6.2B-X Z DIODE
