JVC KD-AR760

19
ENGLISH
Storing your own sound
adjustments
You can adjust the sound modes and store your
own adjustments in memory.
1
2
3
Ex.: When “JAZZ” is selected
4 Select the sound elements to adjust.
LOW LEVEL* = LOW FREQ =
LOW WIDTH = MID LEVEL* =
MID WIDTH = HI (high) LEVEL* =
HI (high) FREQ = (back to the
beginning)
• LEVEL (LOW, MID, HI):
Adjust the enhancement level.
• FREQ (LOW, HI):
Select the center frequency to adjust.
• WIDTH (LOW, MID):
Select the band width level.
* By pressing 4
or ¢, you can
directly move as follows:
5 Adjust the selected sound elements.
Indication
Preset values
LOW MID HI
LEVEL –06
(min.) to
+06
(max.)
–06
(min.) to
+06
(max.)
–06
(min.) to
+06
(max.)
FREQ. 60Hz
80Hz
100Hz
120Hz
8kHz
10kHz
12kHz
15kHz
WIDTH 1 (min.)
to
4 (max.)
1 (min.)
to
2 (max.)
6 Repeat steps 4 and 5 to set (or
adjust) the other sound elements.
7 Select one of the user sound modes
(USER 1, USER 2, USER 3).
8 Store the adjustments.
