JVC KD-DV4304UI User Manual

3-18
Switch board(ADV5380,DV5300)
Block No. [0][2]
Main board
(DV5301,DV5302,DV5307,DV5308)
Block No. [0][3]
 Symbol No. Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
D630 SML-310LT/MN/-X LED
D631 SML-310LT/MN/-X LED
D632 SML-310LT/MN/-X LED
D633 SML-310LT/MN/-X LED
D634 SML-310LT/MN/-X LED
D635 SML-310LT/MN/-X LED
D636 SML-310LT/MN/-X LED
D637 SML-310LT/MN/-X LED
D638 SML-310LT/MN/-X LED
D639 SML-310LT/MN/-X LED
D640 SML-310LT/MN/-X LED
D641 SML-310LT/MN/-X LED
D642 SML-310LT/MN/-X LED
D643 SML-310LT/MN/-X LED
D644 SML-310LT/MN/-X LED
D645 SML-310LT/MN/-X LED
D646 SML-310LT/MN/-X LED
D647 SML-310LT/MN/-X LED
D648 SML-310LT/MN/-X LED
D649 SML-310LT/MN/-X LED
D650 NSPW310BS/B2RST LED
D651 NSPW310BS/B2RST LED
D661 1SS355W-X DIODE
D661 or MA111-X SI DIODE
D662 UDZW5.1B-X SB DIODE
D662 or MA8051/M/-X Z DIODE
C620 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C661 NCB21AK-105X C CAPACITOR 1uF 10V K
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C682 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R601 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R606 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R607 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R610 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R616 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R617 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R622 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R623 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R624 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R630 NRSA02J-621X MG RESISTOR 620 Ω 1/10W J
R632 NRSA02J-621X MG RESISTOR 620 Ω 1/10W J
R634 NRSA02J-621X MG RESISTOR 620 Ω 1/10W J
R636 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R638 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R640 NRSA02J-621X MG RESISTOR 620 Ω 1/10W J
R642 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R644 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R646 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R648 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R650 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R652 NRSA02J-621X MG RESISTOR 620 Ω 1/10W J
R654 NRSA02J-271X MG RESISTOR 270
Ω 1/10W J
R657 NRSA02J-181X MG RESISTOR 180
Ω 1/10W J
R660 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R661 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R662 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R663 NRSA63J-225X MG RESISTOR 2.2M Ω 1/16W J
R664 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R665 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R666 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R667 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R668 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R681 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R682 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
J601 QNS0215-001 3.5 JACK
JS686 QSW1219-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
 IC71 LC72725KM-X IC
IC101 HA17558AF-X IC
DV53
01E,D
V5301
EU,D
V5302
E,DV5
302E
U
IC151 TC4066BFT-X IC
DV53
01E,D
V5301
EU,D
V5302
E,DV5
302E
U
IC161 NJW1192V-X IC
 IC301 TB2904HQ IC
IC401 TC7SET08F-X IC
IC402 TOTX177L OPTICAL JACK
IC411 MM1510XN-X IC
 IC721 UPD78F1166GC1D IC(PROGRAMMED)
IC722 S-24CS16A0I-G-X IC
IC731 IC-PST3433U-X IC
IC731 or S-80833CNNB-G-W IC
IC801 HD74HC126FP-X IC
 IC911 R2S25400DS-E IC
IC921 BA33BC0FP-X IC
IC922 LA5777MP-X IC
IC961 TC74LCX32FT-F-X IC
IC962 TC74VHCT32AFT-X IC
Q1 RT1N141C-X DIGI TRANSISTOR
Q1 or UN2211-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
