JVC KD-DV4304UI User Manual

3-33
Switch board
(DV5304,DV5305,DV5306,DV4304,DV430
5,DV4306)
Block No. [0][6]
RA763 NRZ0065-222X NET RESISTOR 2.2k Ω
L1 QQL244J-4R7Z P COIL 4.7uH J
L401 NQR0007-002X FERRITE BEADS
L411 NQL114K-470X INDUCTOR 47uH K
L752 QQL244J-470Z COIL 47uH J
L901 QQR1378-002 COIL
L911 NQL56CK-220X COIL 22uH K
L921 NQL56CK-220X COIL 22uH K
L922 NQLB7GM-100X COIL 10uH M
L923 NQL71EM-330X COIL 33uH M
CN141 QGA2006C1-04 CONNECTOR W-B (1-4)
DV53
04UI,
DV53
05U,D
V5305
UN,D
V5305
UT,DV
5305A
,DV53
06U,D
V5306
UN,D
V5306
UT,DV
5306A
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN821 QGA2001C1-02 CONNECTOR W-B (1-2)
CN901 QNZ0607-001 CAR CONNECTOR
CN961 QGB2044M1-30 CONNECTOR B-B (1-30)
CN962 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2043L1-30X CONNECTOR B-B (1-30)
J1 QNB0190-001 CAR ANT JACK
J331 QNN0770-001 3P PIN JACK
J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
PP2 QZW0010-001 STYLE PIN
DV53
04UI,
DV53
05U,D
V5305
UN,D
V5305
UT,DV
5305A
,DV53
06U,D
V5306
UN,D
V5306
UT,DV
5306A
S731 QSW0648-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k Ω
 TU1 QAU0484-001 TUNER PACK
X721 QAX0401-001 CRYSTAL 32.768KHz
X722 QAX0916-001Z CRYSTAL
 Symbol No. Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
D630 SML-310LT/MN/-X LED
D631 SML-310LT/MN/-X LED
D632 SML-310LT/MN/-X LED
D633 SML-310LT/MN/-X LED
 Symbol No. Part No. Part Name Description Local
D634 SML-310LT/MN/-X LED
D635 SML-310LT/MN/-X LED
D636 SML-310LT/MN/-X LED
D637 SML-310LT/MN/-X LED
D638 SML-310LT/MN/-X LED
D639 SML-310LT/MN/-X LED
D640 SML-310LT/MN/-X LED
D641 SML-310LT/MN/-X LED
D642 SML-310LT/MN/-X LED
D643 SML-310LT/MN/-X LED
D644 SML-310LT/MN/-X LED
D645 SML-310LT/MN/-X LED
D646 SML-310LT/MN/-X LED
D647 SML-310LT/MN/-X LED
D648 SML-310LT/MN/-X LED
D649 SML-310LT/MN/-X LED
D650 NSPW310BS/B2RST LED
D651 NSPW310BS/B2RST LED
D661 1SS355W-X DIODE
D661 or MA111-X SI DIODE
D662 UDZW5.1B-X SB DIODE
D662 or MA8051/M/-X Z DIODE
C620 NCB31HK-473X C CAPACITOR 0.047uF 50V K
DV53
04UI,
DV53
05U,D
V5305
UN,D
V5305
UT,DV
5305A
,DV53
06U,D
V5306
UN,D
V5306
UT,DV
5306A
C661 NCB21AK-105X C CAPACITOR 1uF 10V K
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C682 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R601 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R606 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R610 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R612 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R616 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R617 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
DV53
04UI,
DV53
05U,D
V5305
UN,D
V5305
UT,DV
5305A
,DV53
06U,D
V5306
UN,D
V5306
UT,DV
5306A
 Symbol No. Part No. Part Name Description Local
