JVC KD-DV5100 Service Manual

3-14
C401 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C402 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C403 NCB31HK-331X C CAPACITOR 330pF 50V K
C404 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C411 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C412 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C421 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C422 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C431 NCB31HK-332X C CAPACITOR 3300pF 50V K
C432 NCS31HJ-471X C CAPACITOR 470pF 50V J
C433 NCS31HJ-471X C CAPACITOR 470pF 50V J
C451 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C452 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C453 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C454 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C481 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C491 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C521 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C522 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C531 NCB31HK-332X C CAPACITOR 3300pF 50V K
C532 NCS31HJ-471X C CAPACITOR 470pF 50V J
C533 NCS31HJ-471X C CAPACITOR 470pF 50V J
R101 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R102 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R103 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R104 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R105 NRS125J-270X MG RESISTOR 27
Ω 1/2W J
R106 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R107 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R108 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R109 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R110 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R111 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R112 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R113 NRS125J-270X MG RESISTOR 27
Ω 1/2W J
R114 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R116 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R117 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R118 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R119 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R120 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R122 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R123 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R125 NRS125J-1R0X MG RESISTOR 1
Ω 1/2W J
R126 NRSA02J-330X MG RESISTOR 33
Ω 1/10W J
R201 NRS125J-1R0X MG RESISTOR 1
Ω 1/2W J
R202 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R203 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R205 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R206 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R207 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R208 NRSA63J-203X MG RESISTOR 20k
Ω 1/16W J
R209 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R211 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R219 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R220 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R221 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R222 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R223 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R224 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R231 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R232 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R233 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R234 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R235 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R251 NRS125J-R47X MG RESISTOR 0.47
Ω 1/2W J
R252 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R253 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R254 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R255 NRSA63J-203X MG RESISTOR 20k
Ω 1/16W J
R256 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R257 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R258 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R259 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J

Symbol
No.
Part No. Part Name Description Local
R260 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R300 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R301 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R303 NRSA63J-270X MG RESISTOR 27
Ω 1/16W J
R306 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R307 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R308 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R309 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R310 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R312 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R313 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R314 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R315 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R316 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R317 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R318 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R319 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R321 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R322 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R323 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R325 NRSA63J-161X MG RESISTOR 160
Ω 1/16W J
R326 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R327 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R328 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R329 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R332 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R333 NRSA63J-163X MG RESISTOR 16k
Ω 1/16W J
R334 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R335 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R336 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R337 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R338 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R339 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R340 NRSA63D-303X MG RESISTOR 30k
Ω 1/16W D
R345 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R346 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R347 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R348 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R349 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R350 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R351 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R352 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R353 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R354 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R355 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R356 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R357 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R358 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R359 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R360 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R361 NQL093K-1R8X COIL 1.8uH K
R362 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R363 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R364 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R365 NRSA63D-911X MG RESISTOR 910
Ω 1/16W D
R366 NRSA63D-202X MG RESISTOR 2k
Ω 1/16W D
R370 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R372 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R373 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R380 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R385 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R386 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R390 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R391 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R392 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R393 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R394 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R396 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R399 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R401 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R402 NRSA63J-4R7X MG RESISTOR 4.7
Ω 1/16W J
R403 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R404 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R411 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R421 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R422 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J

Symbol
No.
Part No. Part Name Description Local
