JVC KD-DV5100 Service Manual

3-15
R431 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R432 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R433 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R434 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R435 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R436 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R437 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R438 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R441 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R442 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R481 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R491 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R492 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R521 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R522 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R531 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R532 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R533 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R534 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R535 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R536 NRSA63J-201X MG RESISTOR 200
Ω 1/16W J
R537 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R538 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R605 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R606 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L303 NQL044K-100X COIL 0.26
Ω 10uH K
L305 NQL093K-1R8X COIL 1.8uH K
L306 NQL093K-1R8X COIL 1.8uH K
L307 NQL093K-1R8X COIL 1.8uH K
L451 NQL044K-100X COIL 0.26
Ω 10uH K
CN101 QGF0522F1-30W CONNECTOR FFC/FPC (1-30)
CN201 QGF1038F1-11X CONNECTOR FFC/FPC (1-11)
CN202 QGF0523F1-05W CONNECTOR FFC/FPC (1-5)
CN402 QGF0522F1-06W CONNECTOR FFC/FPC (1-6)
CN403 QGF0534F1-45X CONNECTOR FFC/FPC (1-45)
K101 NQR0007-002X FERRITE BEADS
K102 NQR0007-002X FERRITE BEADS
K301 NQR0502-001X FERRITE BEADS
K311 NQR0129-002X FERRITE BEADS
K399 NQR0502-001X FERRITE BEADS
K401 NQR0022-005X FERRITE BEADS
K402 NQR0022-005X FERRITE BEADS
K403 NQR0022-005X FERRITE BEADS
K404 NQR0022-005X FERRITE BEADS
K405 NQR0022-005X FERRITE BEADS
K406 NQR0022-005X FERRITE BEADS
K407 NQR0022-005X FERRITE BEADS
K425 NQL093K-1R8X COIL 1.8uH K
K441 NQR0022-005X FERRITE BEADS
K442 NQR0022-005X FERRITE BEADS
K443 NQR0022-005X FERRITE BEADS
K444 NQR0022-005X FERRITE BEADS
K445 NQR0022-005X FERRITE BEADS
K451 NQR0022-005X FERRITE BEADS
K452 NQR0022-005X FERRITE BEADS
K601 NQR0022-005X FERRITE BEADS
SW4 NSW0184-001X DETECT SW
SW5 NSW0183-001X DETECT SW
TH491 NAD0025-103X N THERMISTOR 10k
Ω
X351 NAX0730-001X CRYSTAL

Symbol
No.
Part No. Part Name Description Local
