3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3004-203 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
9 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 GE10079-001A FRONT CHASSIS
12 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
13 GE31033-001A LOCK LEVER
14 FSKW4005-003 TORSION SPRING
15 GE40202-001A
COMPRESSION
SPRING
16 GE31034-001A RLS KNOB
17 GE40156-001A BLIND
18 GE10077-003A FRONT PANEL
AR20
0
18 GE10077-001A FRONT PANEL G200
19 GE31031-015A FINDER ASSY
AR20
0
19 GE31031-014A FINDER ASSY G200
20 GE31027-001A POWER BUTTON
21 GE31038-001A VOLUME KNOB
22 GE31039-002A SEL BUTTON
AR20
0
22 GE31039-001A SEL BUTTON G200
23 GE31040-001A RIM LENS
24 FSYH4036-069 SHEET
25 GE31181-002A D.FUNC BTN
AR20
0
25 GE31029-001A D.FUNC BTN G200
26 GE20161-002A PRESET BUTTON
AR20
0
26 GE20161-001A PRESET BUTTON G200
27 GE31024-004A UP/DOWN BTN
AR20
0
27 GE31024-002A UP/DOWN BTN G200
28 GE31028-001A SSM BTN
29 GE31025-002A SEARCH BTN
AR20
0
29 GE31025-001A SEARCH BTN G200
30 GE31026-001A EJECT BUTTON
31 GE31032-003A DETACH BTN
AR20
0
31 GE31032-002A DETACH BTN G200
32 GE40202-003A
COMPRESSION
SPRING
33 GE10078-001A REAR COVER
34 GE31021-001A LCD CASE
35 GE31022-002A LCD LENS
36 GE31023-001A LENS CASE
37 GE40199-001A LIGHTING SHEET
38 GE40199-002A LIGHTING SHEET
39 GE31053-001A NAME PLATE
AR20
0
39 GE31050-001A NAME PLATE G200
40 QLD0289-001 LCD MODULE
41 QNZ0443-001 LCD CONNECTOR
42 GE30912-008A REAR BRACKET
43 QYSDST2606Z SCREW 2.6mm x 6mm
44 QYSDST2606Z SCREW 2.6mm x 6mm
45 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
46 QYSDSF2606Z SCREW 2.6mm x 6mm
47 GE40172-004A IC BRACKET
48 GE40124-002A REG BRACKET
49 GE30854-001A LED HOLDER
50 GE40218-002A SHEET
51 VKZ4777-001 MINI SCREW (x4)
52 QMFZ047-150-T FUSE 15A
