3-13
Switch board(KD-G227_EE)
Block No. [0][5]
R522 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R523 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R524 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R525 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R526 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R527 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R528 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R529 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R530 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R531 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R532 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R533 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R534 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R535 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R537 NRSA63J-155X MG RESISTOR 1.5M
Ω
1/16W J
R540 NRSA63J-303X MG RESISTOR 30k
Ω
1/16W J
R541 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R542 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R543 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R544 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R545 NRS181J-332X MG RESISTOR 3.3k
Ω
1/8W J
R548 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R554 NRSA63J-4R7X MG RESISTOR 4.7
Ω
1/16W J
R556 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R558 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R559 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R561 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R562 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R565 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R583 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R584 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R585 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R586 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R587 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R588 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R589 NRS181J-0R0X MG RESISTOR 0
Ω
1/8W J
R590 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R591 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R592 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R593 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R594 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R701 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R705 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R706 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R707 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R708 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R709 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R710 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R711 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R712 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R713 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R715 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R716 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R717 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R718 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R727 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R730 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R731 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R732 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R733 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R735 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R736 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R737 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R739 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R740 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R741 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R742 NRS181J-512X MG RESISTOR 5.1k
Ω
1/8W J
R743 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R745 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R748 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R749 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R751 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R752 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R753 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R754 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
Symbol No.
Part No. Part Name Description Local
R755 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R756 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R762 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R901 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R902 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R903 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R905 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R906 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R907 NRS181J-123X MG RESISTOR 12k
Ω
1/8W J
R908 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R909 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R910 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R911 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R912 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0773-001 PIN JACK
TU1 QAU0394-003 TUNER PACK
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0406-001Z CRYSTAL 4.500MHz
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
Q670 2SA1365/F/-X TRANSISTOR
Q671 RT1N141C-X DIGI TRANSISTOR
D630 SML-310LT/MN/-X LED
D631 LNJ308G81/1-3/X LED
D632 LNJ308G81/1-3/X LED
D634 LNJ308G81/1-3/X LED
D635 LNJ308G81/1-3/X LED
D636 LNJ308G81/1-3/X LED
D637 LNJ308G81/1-3/X LED
D638 LNJ308G81/1-3/X LED
D639 LNJ308G81/1-3/X LED
D640 LNJ308G81/1-3/X LED
D641 LNJ308G81/1-3/X LED
D642 LNJ308G81/1-3/X LED
D643 LNJ308G81/1-3/X LED
D644 LNJ308G81/1-3/X LED
D645 LNJ308G81/1-3/X LED
D646 LNJ308G81/1-3/X LED
D647 LNJ308G81/1-3/X LED
D648 LNJ308G81/1-3/X LED
D649 LNJ308G81/1-3/X LED
D652 NSPW310BS/BRST/ WHITE LED
D653 NSPW310BS/BRST/ WHITE LED
D661 1SS355W-X DIODE C.M
D662 UDZW5.1B-X SI DIODE
D681 UDZW6.2B-X SI DIODE
C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NDC31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C682 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
