3-21
Switch board(KD-G327_EE)
Block No. [0][11]
Function board(KD-G327_EE)
Block No. [0][12]
R777 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R802 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R804 NRS181J-203X MG RESISTOR 20k
Ω
1/8W J
R805 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R807 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R891 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R892 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R901 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R902 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R903 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R905 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R906 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R911 NRSA02J-123X MG RESISTOR 12k
Ω
1/10W J
R912 NRSA02J-273X MG RESISTOR 27k
Ω
1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
L1 QQL801K-4R7Y COIL 4.7uH K
L2 NQL093K-R22X COIL 0.22uH K
L701 QQL801K-4R7Y COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0773-001 PIN JACK
S775 QSW1049-001Z TACT SW
TU1 QAU0453-001 TUNER PACK
X71 QAX0263-001Z CRYSTAL 4.332MHz
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0667-001Z C RESONATOR 8.000MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
Q670 2SA1365/F/-X TRANSISTOR
Q671 RT1N141C-X DIGI TRANSISTOR
D630 SML-310LT/MN/-X LED
D631 SML-310VT/JK/-X LED
D633 SML-310VT/JK/-X LED
D635 SML-310VT/JK/-X LED
D636 SML-310VT/JK/-X LED
D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D652 NSPW310BS/BRST/ WHITE LED
D653 NSPW310BS/BRST/ WHITE LED
D661 1SS355W-X DIODE C.M
D662 UDZW5.1B-X SI DIODE
D681 UDZW6.2B-X SI DIODE
C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C682 NCB31HK-123X C CAPACITOR 0.012uF 50V K
Symbol No.
Part No. Part Name Description Local
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R610 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R630 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R631 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R633 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R637 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R639 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R641 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R643 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R645 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R649 NRS181J-391X MG RESISTOR 390
Ω
1/8W J
R650 NRS181J-391X MG RESISTOR 390
Ω
1/8W J
R661 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R662 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R663 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R664 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R665 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R666 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R667 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R668 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R670 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R671 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R672 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R681 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R682 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R686 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
IC501 LA6242H-X IC
Q501 2SA1705/ST/-T TRANSISTOR
C501 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C503 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C504 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
