3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3005-001 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
9 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 QYSDSF2006M SCREW 2mm x 6mm(x2)
12 GE30823-001A F. CHASSIS ASSY
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 FSYH4036-098 SHEET
15 GE30827-002A OPEN LEVER
16 GE30824-002A LOCK LEVER(O.L)
17 GE31245-001A RELEASE LEVER
18 GE30829-001A LOCK LEVER(TOP)
19 GE30825-002A LOCK LEVER(L)
20 GE30828-002A LOCK LEVER(R)
21 GE40154-001A GEAR
22 QZW0108-002 OIL DAMPER
23 GE40153-001A T.SPRING
24 GE40157-001A T.SPRING
25 VKW5264-005 T.SPRING
26 FSKW4012-002 T.SPRING
27 VKW5263-002 T.SPRING
28 GE40155-001A T.SPRING
29 QYSDSF2006M SCREW 2mm x 6mm
30 GE40156-001A BLIND
31 GE10080-003A FRONT PANEL
AR40
0J
31 GE10080-002A FRONT PANEL G400J
32 GE31048-004A FINDER ASSY
AR40
0J
32 GE31048-002A FINDER ASSY G400J
33 GE31044-001A POWER BUTTON
34 GE31038-001A VOLUME KNOB
35 GE40218-002A SHEET
36 GE31039-004A SEL BUTTON
AR40
0J
36 GE31039-003A SEL BUTTON G400J
37 GE31040-001A RIM LENS
38 FSYH4036-069 SHEET
39 GE31181-002A D.FUNC BTN
AR40
0J
39 GE31029-001A D.FUNC BTN G400J
40 GE20161-002A PRESET BUTTON
AR40
0J
40 GE20161-001A PRESET BUTTON G400J
41 GE31043-003A UP/DOWN BTN
AR40
0J
41 GE31043-001A UP/DOWN BTN G400J
42 GE31028-003A SSM BTN
43 GE31025-002A SEARCH BTN
AR40
0J
43 GE31025-001A SEARCH BTN G400J
44 GE31041-003A EJECT BUTTON
AR40
0J
44 GE31041-002A EJECT BUTTON G400J
45 GE31250-001A EJECT COVER
46 GE40220-001A LIGHT SHIELD
47 GE31042-003A DETACH BUTTON
AR40
0J
47 GE31042-002A DETACH BUTTON G400J
48 GE31045-001A RIM COVER
49 GE40204-001A JVC BADGE
50 VKW3001-330 COMP.SPRING
51 GE40202-004A COMP.SPRING
52 GE10081-001A REAR COVER
53 VKZ4777-001 MINI SCREW (x4)
54 GE31035-001A LCD CASE
55 GE31036-001A LCD LENS
56 GE31037-001A LENS CASE
57 GE40200-003A LIGHTING SHEET
58 GE31118-002A NAME PLATE
AR40
0J
58 GE31115-002A NAME PLATE G400J
59 QLD0297-001 LCD MODULE
60 QNZ0442-001 LCD CONNECTOR
61 QMFZ047-150-T FUSE 15A
62 GE30912-006A REAR BRACKET
63 QYSDST2606Z SCREW 2.6mm x 6mm
64 FSKZ4005-001 SCREW
65 QYSDST2606Z SCREW 2.6mm x 6mm
66 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
67 QYSDSF2606Z SCREW 2.6mm x 6mm
68 GE40172-004A IC BRACKET
69 GE40124-002A REG BRACKET
70 GE30854-001A LED HOLDER
71 FSYH4036-053 SHEET
