3-11
Switch board (UT.UH.UN.U)
Block No. [0][2]
R726 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R728 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R734 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R735 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R736 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R741 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R743 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R744 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R745 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R746 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R747 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R748 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R749 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R750 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R751 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R752 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R753 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R754 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R755 NRSA63J-106X MG RESISTOR 10M
Ω
1/16W J
R756 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R757 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R758 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R759 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R763 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R765 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R771 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R772 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R774 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R776 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R804 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R811 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R851 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω
1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R976 NRSA02J-273X MG RESISTOR 27k
Ω
1/10W J
R977 NRSA02J-123X MG RESISTOR 12k
Ω
1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L401 NQL114K-470X INDUCTOR 47uH K
L402 NQL114K-470X INDUCTOR 47uH K
L404 NQL114K-470X INDUCTOR 47uH K
L541 NQL114K-470X INDUCTOR 47uH K
L543 NQL114K-470X INDUCTOR 47uH K
L544 NQL114K-470X INDUCTOR 47uH K
L701 QQL244J-4R7Z COIL 4.7uH J
L702 NQL79GM-4R7X COIL 4.7uH M
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0519-001 PIN JACK
TU1 QAU0312-002 TUNER PACK
X31 QAX0616-001Z CRYSTAL 10.250MHz
X401 QAX0413-001Z CRYSTAL 16.9344MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q671 2SB624/4/-X TRANSISTOR
Q672 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310LT/MN/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310LT/MN/-X LED
D618 SML-310LT/MN/-X LED
D631 NSPW310BS/BRST/ WHITE LED
D632 NSPW310BS/BRST/ WHITE LED
D641 MA8051/M/-X Z DIODE
D643 MA111-X SI DIODE
D644 MA8062/M/-X Z DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R627 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R628 NRSA02J-391X MG RESISTOR 390
Ω
1/10W J
R629 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R630 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R632 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R634 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R636 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R638 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R640 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R642 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R644 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R661 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R662 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R671 NRSA02J-471X MG RESISTOR 470
Ω
1/10W J
R672 NRSA02J-473X MG RESISTOR 47k
Ω
1/10W J
R673 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
