3-12
Main board (UT2.UH2.UN2.U2)
Block No. [0][3]
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC161 TEA6320T-X IC
IC301 LA47516 POWER IC
IC501 AN41012A-W IC
IC521 MN6627945ECUC IC
IC523 SN74LVC07ANS-X LOGIC IC
IC581 NJM4565M-WE IC
IC701 LC723784-9C90 IC
IC901 AN80T71 REGULATOR IC
IC981 NJU7772F15-X IC
Q1 UN2211-X TRANSISTOR
Q2 UN2211-X TRANSISTOR
Q4 UN2211-X TRANSISTOR
Q5 2SB1197K/QR/-X TRANSISTOR
Q6 2SB709A/QR/-X TRANSISTOR
Q31 2SD601A/QR/-X TRANSISTOR
Q32 2SD601A/QR/-X TRANSISTOR
Q301 2SD601A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q521 2SB709A/QR/-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2111-X TRANSISTOR
Q902 2SD601A/QR/-X TRANSISTOR
Q903 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MA111-X SI DIODE
D4 MA111-X SI DIODE
D6 MA111-X SI DIODE
D301 UDZS3.3B-X Z DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D501 1A3G-T1 SI DIODE
D703 MA111-X SI DIODE
D706 MA111-X SI DIODE
D711 MA8062/M/-X Z DIODE
D712 MA8062/M/-X Z DIODE
D713 MA8062/M/-X Z DIODE
D714 MA8062/M/-X Z DIODE
D715 MA8062/M/-X Z DIODE
D716 MA8062/M/-X Z DIODE
D717 MA8062/M/-X Z DIODE
D718 MA8062/M/-X Z DIODE
D719 MA8062/M/-X Z DIODE
D720 MA8062/M/-X Z DIODE
D721 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA8110/M/-X Z DIODE
D901 1N5401-F64 DIODE
D903 MA111-X SI DIODE
D904 RB160M-30-X SB DIODE
D905 RB160M-30-X SB DIODE
D906 RB160M-30-X SB DIODE
D907 RB160M-30-X SB DIODE
C1 NDC31HJ-221X C CAPACITOR 220pF 50V J
C2 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C3 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C4 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C6 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C8 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NCB31HK-331X C CAPACITOR 330pF 50V K
C31 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C32 NCB31HK-102X C CAPACITOR 1000pF 50V K
C33 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C81 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C82 NCB31HK-562X C CAPACITOR 5600pF 50V K
C83 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
