JVC KD-G525 Service Manual

3-22
Switch board (KD-G527)
Block No. [0][7]
R646 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
AR470J
G420J
G524UI
G525U
G525UH
G525UN
G525UT
G527EE
R648 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
G521E
G521EU
G521EX
G521EY
R648 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
G420J
G524UI
G525U
G525UH
G525UN
G525UT
R648 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
AR470J
G527EE
R651 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R653 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R654 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R655 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R656 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R657 NRSA63J-513X MG RESISTOR 51k Ω 1/16W J
R658 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R660 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R661 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R672 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R673 NRSA02J-473X MG RESISTOR 47k Ω 1/10W J
R674 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
R691 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R692 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER
J601 QNS0245-001 AUX JACK
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
 Symbol No. Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q640 2SA1365/F/-X TRANSISTOR
Q641 RT1N141C-X DIGI TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
 Symbol No. Part No. Part Name Description Local
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MC2838-X DIODE
D641 UDZW5.1B-X SI DIODE
D642 1SS355W-X DIODE C.M
D643 UDZW6.2B-X SI DIODE
D645 NSPW310BS/B2RST LED
AR470J
G420J
D645 NSPW310BS/BRST/ WHITE LED
G521E
G521EU
G521EX
G521EY
G524UI
G525U
G525UH
G525UN
G525UT
G527EE
D646 NSPW310BS/B2RST LED
AR470J
G420J
D646 NSPW310BS/BRST/ WHITE LED
G521E
G521EU
G521EX
G521EY
G524UI
G525U
G525UH
G525UN
G525UT
G527EE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R606 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R607 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R608 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R611 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R612 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R613 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R614 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R630 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
G420J
G524UI
G525U
G525UH
G525UN
G525UT
R630 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
AR470J
G521E
G521EU
G521EX
G521EY
G527EE
R631 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
AR470J
G527EE
R632 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
G420J
G521E
G521EU
G521EX
G521EY
G524UI
G525U
G525UH
G525UN
G525UT
R632 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
AR470J
G527EE
R633 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
AR470J
G527EE
R634 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
G521E
G521EU
G521EX
G521EY
R634 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
G420J
G524UI
G525U
G525UH
G525UN
G525UT
R634 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
AR470J
G527EE
R636 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
G521E
G521EU
G521EX
G521EY
 Symbol No. Part No. Part Name Description Local
