JVC KD-G700 Service Manual

3-3
General Assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 GE20156-001A GEAR BKT UNIT
2 FSYH4036-100 SHEET
3 GE30968-001A LEVER BKT UNIT
4 GE30964-001A LOWER LEVER ASS
5 GE30975-001A FRONT BKT ASSY
6 FSYH4036-100 SHEET
7 GE30972-001A DETACH LEVER
8 GE30973-001A KICK LEVER
9 GE40192-001A SHAFT
10 GE40193-001A SHAFT
11 WDL123525 WASHER (x2)
12 WDL215025 WASHER (x2)
13 GE40194-001A T SPRING
14 GE40195-002A T.SPRING
15 GE40218-009A SHEET (x2)
16 GE10073-004A TOP CHASSIS
17 GE40135-001A EARTH PLATE
18 GE10074-001A BOTTOM CHASSIS
19 GE10075-001A FRONT CHASSIS
20 GE40156-001A BLIND
21 GE40224-001A MIRROR SHEET (x2)
22 GE30974-001A FPC GUIDE
23 GE40196-001A ABSORBER (x2)
24 GE31204-003A INSULATOR
25 GE31206-002A HEAT SINK
26 QYSPSP2003M SCREW 2mm x 3mm(x2)
27 QYSPSTU2040M TAP SCREW M2 x 4mm(x2)
28 LV42181-002A SPECIAL SCREW (x2)
29 LV40865-001A MINI SCREW (x2)
30 LV40865-001A MINI SCREW (x3)
31 LV40865-001A MINI SCREW
32 LV41200-001A SPECIAL SCREW (x2)
33 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
34 QYSDST2604Z SCREW 2.6mm x 4mm
35 QYSDST2604Z SCREW 2.6mm x 4mm
36 LV41200-001A SPECIAL SCREW (x2)
37 FSKZ4005-002 SCREW (x2)
38 QYSDST2610Z SCREW 2.6mm x 10mm(x2)
39 QYSDST2612Z SCREW 2.6mm x 12mm
40 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
41 QYSDST2604Z SCREW 2.6mm x 4mm(x2)
42 GE10084-001A FRONT PANEL
43 GE31184-001A FINDER ASSY
44 GE31199-001A COVER PLATE L
45 GE31218-001A COVER PLATE R
46 GE31198-001A COVER PLATE B
47 GE31189-001A DISPLAY BUTTON
48 GE31190-001A ANGLE BUTTON
49 GE31185-001A POWER BUTTON
50 GE31186-001A MODE BUTTON
51 GE31187-001A EJECT BUTTON
52 GE20166-001A PRESET BUTTON
53 GE31191-003A D.FUNC BUTTON
54 GE31192-001A SEARCH BUTTON
55 GE31193-001A UP/DOWN BUTTON
56 GE31197-001A RIM LENS (x2)
57 GE31196-001A RIM COVER
58 FSYH4036-032 SHEET
59 GE40218-002A SHEET
60 GE31195-002A SEL BUTTON
61 GE31194-001A KNOB
62 GE31188-001A DETACH BUTTON
63 FSKW3002-012 COMP.SPRING
64 GE10085-001A REAR COVER
65 GE40211-001A REAR LENS
66 GE40216-001A REAR LENS (R)
67 GE40218-010A SHEET (x2)
68 VKZ4777-001 MINI SCREW (x4)
69 GE40204-001A JVC BADGE
70 GE40218-005A SHEET (x2)
71 GE31201-002A LCD CASE
72 GE31036-001A LCD LENS
73 GE31037-001A LENS CASE
74 GE40200-002A LIGHTING SHEET
75 GE31154-003A NAME PLATE
76 QLD0296-001 LCD MODULE LCD1
77 QNZ0442-001 LCD CONNECTOR
78 QNZ0442-001 LCD CONNECTOR
79 QAL0536-001 FPC CABLE
80 QNZ0664-001 CAR CONNECTOR
 81 QMFZ047-150-T FUSE 15A
82 GE31205-004A REAR BRACKET
83 GE40207-001A POWER IC BKT
84 GE40124-002A REG BRACKET
85 QYSDSF2606Z SCREW 2.6mm x 6mm
86 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
87 QYSDST2604Z SCREW 2.6mm x 4mm
88 FSKS3017-002 LED HOLDER
89 GE40218-011A SHEET
 Symbol No. Part No. Part Name Description Local
