General Assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE20156-001A GEAR BKT UNIT
2 FSYH4036-100 SHEET
3 GE30968-001A LEVER BKT UNIT
4 GE30964-001A LOWER LEVER ASS
5 GE30975-001A FRONT BKT ASSY
6 FSYH4036-100 SHEET
7 GE30972-001A DETACH LEVER
8 GE30973-001A KICK LEVER
9 GE40192-001A SHAFT
10 GE40193-001A SHAFT
11 WDL123525 WASHER (x2)
12 WDL215025 WASHER (x2)
13 GE40194-001A T SPRING
14 GE40195-002A T.SPRING
15 GE40218-009A SHEET (x2)
16 GE10073-004A TOP CHASSIS
17 GE40135-001A EARTH PLATE
18 GE10074-001A BOTTOM CHASSIS
19 GE10075-001A FRONT CHASSIS
20 GE40156-001A BLIND
21 GE40224-001A MIRROR SHEET (x2)
22 GE30974-001A FPC GUIDE
23 GE40196-001A ABSORBER (x2)
24 GE31204-003A INSULATOR
25 GE31206-002A HEAT SINK
26 GE40107-002A HEAT SINK
27 QYSPSP2003M SCREW 2mm x 3mm(x2)
28 QYSPSTU2040M TAP SCREW M2 x 4mm(x2)
29 LV42181-002A SPECIAL SCREW (x2)
30 LV40865-001A MINI SCREW (x2)
31 LV40865-001A MINI SCREW (x3)
32 LV40865-001A MINI SCREW
33 LV41200-001A SPECIAL SCREW (x2)
34 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
35 QYSDST2604Z SCREW 2.6mm x 4mm
36 QYSDST2604Z SCREW 2.6mm x 4mm
37 LV41200-001A SPECIAL SCREW (x2)
38 FSKZ4005-002 SCREW (x2)
39 QYSDST2610Z SCREW 2.6mm x 10mm(x2)
40 QYSDST2610Z SCREW 2.6mm x 10mm
41 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
42 QYSDST2604Z SCREW 2.6mm x 4mm(x2)
43 QYSDST2004Z SCREW 2mm x 4mm(x5)
44 GE40218-011A SHEET
45 GE10084-001A FRONT PANEL
46 GE31184-004A FINDER ASSY
47 GE31199-001A COVER PLATE L
48 GE31218-001A COVER PLATE R
49 GE31198-001A COVER PLATE B
50 GE31189-001A DISPLAY BUTTON
51 GE31190-001A ANGLE BUTTON
52 GE31185-001A POWER BUTTON
53 GE31186-001A MODE BUTTON
54 GE31187-001A EJECT BUTTON
55 GE20166-001A PRESET BUTTON
56 GE31191-001A D FUNC BUTTON
57 GE31192-001A SEARCH BUTTON
58 GE31193-001A UP/DOWN BUTTON
59 GE31197-001A RIM LENS (x2)
60 GE31196-001A RIM COVER
61 FSYH4036-032 SHEET
62 GE40218-002A SHEET
63 GE31195-002A SEL BUTTON
64 GE31194-001A KNOB
65 GE31188-001A DETACH BUTTON
66 FSKW3002-012 COMP.SPRING
67 GE10085-001A REAR COVER
68 GE40211-001A REAR LENS (L)
69 GE40216-001A REAR LENS (R)
70 GE40218-010A SHEET (x2)
71 VKZ4777-001 MINI SCREW (x4)
72 GE40204-001A JVC BADGE
73 GE40218-005A SHEET (x2)
74 GE31201-002A LCD CASE
75 GE31036-001A LCD LENS
76 GE31037-001A LENS CASE
77 GE40200-002A LIGHTING SHEET
78 GE31145-002A NAME PLATE
79 LV41843-002A LASER CAUTION
80 QLD0296-001 LCD MODULE
81 QNZ0442-001 LCD CONNECTOR
82 QNZ0442-001 LCD CONNECTOR
83 QUQ105-2207AE FFC WIRE
84 VYSH101-009 SPACER
85 QAL0536-001 FPC CABLE
86 QNZ0664-001 CAR CONNECTOR
87 QAM0547-001 SUBWOOFER CABEL
88 VYTA500-001 PIN CAP (x2)
89 QMFZ047-150-T FUSE 15A
91 GE31205-003A REAR BRACKET
92 GE40207-001A POWER IC BKT
93 GE40208-001A REG IC BKT
94 QYSDSF2606Z SCREW 2.6mm x 6mm
95 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
96 QYSDST2604Z SCREW 2.6mm x 4mm
97 QYSDST2606Z SCREW 2.6mm x 6mm
98 GE40214-001A WIRE HOLDER
99 QYSDST2604Z SCREW 2.6mm x 4mm
100 FSKS3017-002 LED HOLDER
