1A OUT
2A -IN
3A +IN
4
8
7
6
5GND
V
+
B OUT
B -IN
B +IN
NJM2904M-W (IC831) : Ope amp
Q8
Q1 Q4
Q2 Q3
Q8 Q9
Q10
Q11
Q12
Q13
OUTPUT
Q7
Q6
Q5
V+
1.Pin layout
2.Block diagram
