JVC KD-LX50R Service Manual

Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 ------------ CD MECHA 1
2 LV41606-001A FFC P.MECHA 1
3 LV10189-001A-N CHASSIS TOP 1
4 LV10188-001A FRONT COVER 1
5 LV40828-002A BLIND 1
6 LV31602-003A SIDE HEAT SINK 1
7 LV31603-001A INSULATOR 1
8 QYSPST2004M SCREW 1
9 QYSDST2604Z SCREW 3 T. CHAS+CD MECH
10 QYSDSF2610Z TAPPING SCREW 1 T. CHAS+S HEAT
11 LV41200-003A SPESIAL SCREW 3 T. CHAS+S HEAT
12 LV41200-003A SPESIAL SCREW 1 T.CHASS+REAR
13 QYSDST2604Z SCREW 8 T. CHAS+B. CHAS
14 LV40847-002A SPACER 1 MOTOR L
15 LV41200-001A SPECIAL SCREW 1 BOTTOM CHA.+REA
16 QYSPSP2003M SCREW 4 T. CHAS+F. COVE
17 LV41200-001A SPECIAL SCREW 3 MAIN PWB+BOTTOM
18 LV31605-001A DOOR BASE ASS'Y 1
19 LV41452-001A TENS SPRING BTM 2
20 LV31607-001A PANEL COVER 1
21 LV31965-001A BUTTON BASE BKT 1
22 LV41500-001A BUTTON B.SUPORT 1
23 LV41545-001A BUTTON B.GUIDE 1
24 LV31609-001A FRONT BKT ASS'Y 1
25 LV20614-001A LOADING BKT ASS 1
26 WDM215025 WASHER 4
27 LV41503-001A ARM 3 2
28 LV31777-001A FFC GUIDE 1
29 LV31610-001A ROD GEAR 1
30 LV31604-001A BOTTOM ASS'Y 1
31 QAR0029001-SA2 FEED MOTOR 1 FOR BKT MOTOR L
32 PPN13KA10C-SA6 MOTOR 1 FOR BKT MOTOR R
33 LV40847-002A SPACER 1 MOTOR R
34 WJM0137-001A E-SI C WIRE C-F 1 FOR MOTOR L
35 WJM0136-001A E-SI C WIRE C-F 1 FOR MOTOR R
36 QWTA20H-030 UL VINYL TUBE 1
39 LV41463-001A GEAR 1 1 R SIDE
40 LV41464-001A GEAR 2 1 R SIDE
41 LV31611-001A GEAR 3 1 R SIDE
42 LV41467-001A GEAR 5 1 L SIDE
43 LV41466-001A GEAR 4 1 L SIDE
44 LV31612-001A GEAR 6 1 L SIDE
45 LV30981-005A *CLUTCH ASS'Y 1
46 QYSPSPT2020Z MINI SCREW 4 F.MOTOR+B.M. L
48 LV40865-001A MINI SCREW 4 ROD BKT
(
L
)
+LO.B
50 LV40865-001A MINI SCREW 3 B.BASE BKT+BO.C
52 LV40865-001A MINI SCREW 1 B.B.GUIDE+BOT.C
53 LV40865-001A MINI SCREW 4 BKT.M.L&R+C.BOT
(General assembly)
54 WDM215025 WASHER 6
