JVC KD-R516

15ENGLISH
Category Menu item Selectable setting, [Initial: Underlined]
AUDIO
L/O MODE
Line output
mode
• SUB.W
• REAR
: Select if the REAR LINE OUT terminals are
used for connecting a subwoofer (through
an external amplifier).
: Select if the REAR LINE OUT terminals are
used for connecting the speakers (through
an external amplifier).
SUB.W FREQ *
5
Subwoofer cutoff
frequency
• LOW
• MID
• HIGH
: Frequencies lower than 72 Hz are sent to the
subwoofer.
: Frequencies lower than 111 Hz are sent to
the subwoofer.
: Frequencies lower than 157 Hz are sent to
the subwoofer.
SUB.W LEVEL *
5
Subwoofer level
SUB.W 00 —
SUB.W 08
[SUB.W 04]
: Adjust the subwoofer output level.
BEEP
Keytouch tone
• BEEP ON
• BEEP OFF
: Activates the keypress tone.
: Deactivates the keypress tone.
AMP GAIN *
6
Amplifier gain
control
• LOW POWER
• HIGH POWER
: VOLUME 00 – VOLUME 30 (Select if the
maximum power of each speaker is less than
50 W to prevent damaging the speakers.)
: VOLUME 00 – VOLUME 50
SRC SELECT
AM *
7
AM station
• AM ON
• AM OFF
: Enable “AM” in source selection.
: Disable “AM” in source selection.
AUX IN *
8
Auxiliary input
• AUX ON
• AUX OFF
: Enable “AUX IN” in source selection.
: Disable “AUX IN” in source selection.
*
5
Displayed only when <L/O MODE> is set to <SUB.W>.
*
6
The volume level automatically changes to “VOLUME 30” if you change to <LOW POWER> with the
volume level set higher than “VOLUME 30.”
*
7
Displayed only when any source other than “AM” is selected.
*
8
Displayed only when any source other than “AUX IN“ is selected.
