NTK-0929-09
KD-R740BT
Bluetooth
®
Wireless Technology USB/CD Receiver with AUX
Dimensions (W × H × D)
Installation Size 7
3/16
” × 2
1/8
” × 6
5/16
” 181.7 × 52.7 × 159 mm
Panel Size 7
7/16
” × 2
3/8
” ×
9/16
” 188 × 58.5 × 12.6 mm
Detachable Face Plate 6
3/4
” × 1
13/16
” ×
7/8
” 169.8 × 46.4 × 22 mm
Maximum Power Output 50W × 4
LPF (Subwoofer) off/55/85/120Hz/Through (-12dB/oct)
Line Pre-Output Terminals 2 (Front + Rear/Subwoofer Selectable)
Subwoofer Output with
Level/Frequency Control
✔
Line Output Level 2.5V
Subwoofer Output Level 2.5V
Subwoofer Gain Control -15dB – +15dB
Load Impedance 4Ω (4 - 8Ω allowable)
Line Output Impedance ; 600Ω
Key Specifications
Connections
Android*
Mass Storage
Audio Streaming
AVRCP
Apps Control
iPhone
Audio Streaming
AVRCP
Apps Control
Mass Storage
Audio Streaming
AVRCP
BlackBerry
®
*
* Compatibility
depends on model
iPodPortable
Audio Players
AUX-IN
Front
USB Memory
USB Cable
HDD*
Rear Panel
✹Steering Wheel Remote Ready
With an optional adapter, you can control an advanced JVC
headunit from the steering wheel remote control that comes
factory standard with your car.
✹Bluetooth
®
Compatible Functions
In addition to hands-free calling, voice recognition dialing,
audio streaming/control, and remote control features with
your smartphone, you can transfer up to 400 contact
numbers to the headunit. With PBAP compatible cell
phones, you can access your phone book without
transferring to the headunit. Two phones can
remain connected continuously.
The features are also available for smartphones.
Hands-Free Calls
Audio Streaming
& Control
Phone Book
Access
Phone Book
Transfer
2 Phones
Full-Time Connection
✔
✔
✔
✔
✔
So Many Features!
Wired MIC
included
✹1A USB Audio for iPod/iPhone and Smartphones
Connect your iPod/iPhone or other smartphones to the unit’s 1A USB
port, and enjoy music in clear, digital sound with full-speed transfer.
Your device’s battery will be charged
during connection.
1A Support
✹Speed Dial with 6-Key Presets
Numbers stored in preset for
2 connected phones can be easily
dialed from the headunit’s 6 keys.
Maximum 30 numbers for 5 phones
can be registered.
Easy to Call
What you can do:
• Control from headunit
• Title Browsing
• Mood Play
✹JVC Original Apps/Software for Smartphone/Devices
JVC Music Control (for Android™)*
JVC Music Control is a free download app that
allows Android users to listen to favorite songs
through an iPod like browsing experience via USB
Mass Storage Mode. Browse music by Artist, Album or Song Title through the headunit.
Also generates playlists based on a particular Mood, much like a personal DJ.
* Smartphones with Android™ 2.2 and above.
JVC Playlist Creator
Use PC software (for Windows
®
) to create a Playlist of
tunes on USB memory which can be used in your car.
USB memory
✹Easy/Pro EQ Setting (3-Band Parametric iEQ)
Adjusts the center frequency, bandwidth and levels at each of 3 bands. Plus 5 initial
and 1 user EQ presets. With Pro mode, the EQ can customize the sound for your
ears. A separate setting for the subwoofer level is also available.
Initial Presets
• DYNAMIC
• FLAT
• NATURAL
• VOCAL BOOST
• BASS BOOST
Control Range Bass: 60Hz, 80Hz, 100Hz, 200Hz
Mid-range
: 500Hz, 1kHz, 1.5kHz, 2.5kHz
Treble: 10kHz,
12.5kHz,
15kHz, 17.5kHz
Bass/Middle/Treble Level -6 – +6 level
Q (Band with) 0.75~2.0Q
✹Apps Control for iPod Mode
Song information display and
certain control features are
available on the headunit for some
apps, when the app is launched
during iPod Mode.
iPod Mode
Speed Trap Area!
Add the buttons for
Thumbs-up/down
✹Pandora via Bluetooth
®
(for Android™/BlackBerry
®
)
Via Bluetooth
®
connection with your Android™/BlackBerry
®
device, you
can listen to as well as control the Pandora app on the headunit.
Thumbs-up/down, forward skip, pause/play, and search station/bookmark
can all be controlled with the unit’s keys.
✹Siri Eyes-Free-Mode for iPod/iPhone
This function allows access to the “Siri” voice-activated
personal assistant while keeping your hands on the steering
wheel and eyes on the road. No need to watch or touch the
iPhone screen as you play back music stored on iPhone, and make calls to registered
phone numbers via Bluetooth-equipped car receiver, with the safety of voice control.
Moreover, “Siri Eyes-Free-Mode” can be easily accessed using the Bluetooth/Voice
Button as is the case with Voice Guidance.
* Depending on the in-car environment or iPhone/iPod environment being used, there may be cases where smooth
operation is not attainable.
USB
Front
*
Not compatible with NTFS format.
