Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
Caution
Select a crossover type according to how the speakers are connected.
(
29
)
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or low.
SPK SIZE
(speaker size)
Selects according to the connected speaker size for optimum
performance.
•
The frequency and slope settings are automatically set for the
crossover of the selected speaker.
•
If [
NONE
] is selected for [
TWEETER
] of [
FRONT
], [
REAR
] and [
SUBWOOFER
] for
[
SPK SIZE
], the [
X ‘ OVER
] setting of the selected speaker is not available.
X ‘ OVER
(crossover)
[
FRQ
]/ [
HPF FRQ
]/ [
LPF FRQ
]:
Adjusts the crossover frequency for the selected speakers (high pass
filter or low pass filter).
•
If [
THROUGH
] is selected, all signals are sent to the selected speakers.
[
SLOPE
]/ [
HPF SLOPE
]/ [
LPF SLOPE
]
:
Adjusts the crossover slope.
•
Selectable only if a setting other than [
THROUGH
] is selected for the
crossover frequency.
[PHASE]:
Selects the phase of the speaker output to be in line with the other
speaker output.
[
GAIN LEFT
]/ [
GAIN RIGHT
]/ [
GAIN
]:
Adjusts the output volume of the selected speaker.
(For
KD-R771BT
)
Setting on
[
SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
REAR/REAR
Rear speakers output
REAR/SUB.W
(default) Subwoofer output
SUB.W/SUB.W
Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output.
(
29
)
Setting on
[
SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR
Rear speakers output Rear speakers output
REAR/SUB.W
Rear speakers output Rear speakers output
SUB.W/SUB.W
Subwoofer output (Mute)
If [
SUB.W/SUB.W
] is selected:
– [
HIGH 120HZ
] is selected in [
SUB.W
LPF
] and [
THROUGH
] is not available.
– [
R02
] is selected in [
FADER
] and selectable range is [
R15
]to [
00
]
AUDIO SETTINGS
