JVC KD-R990BTS User Manual

ENGLISH
31
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
You can control the unit with the steering remote control keys on your vehicle. After connection,
you can configure the control keys according to your preference.
• You can only make this configuration if your vehicle is equipped with the electrical steering
remote control.
• If the steering remote control in your car is not compatible, configuration may not be completed
and an error message may appear.
( 36)
Make the connection
Configure the control keys
1
Press and hold .
2 Turn the volume knob to select [SYSTEM] , then press the knob.
3 Turn the volume knob to select [USER S.REMO] , then press the knob.
4 Turn the volume knob to select [SET KEY] , then press the knob.
A key list of 16 assignable keys appears.
• K## NONE : No function has been assigned.
5 Turn the volume knob to select any key from the key list to assign the function, then press
the knob.
“PRESS KEY TO ASSIGN K##” appears.
DISPLAY SETTINGS
MENU COLOR ON : The color of button illumination
changes to white color when in menu
mode or when selecting a music file
from a folder/list.;
OFF :Cancels.
*
1
The illumination control wire connection is required.
( 42)
*
2
Some characters or symbols will not be shown correctly
(or will be blanked).
*
3
If one of these color pattern is selected, the [ZONE 1]
and
[ZONE 2] illumination colors will change to the
default colors.
LEARNING STEERING REMOTE CONTROL (for KD-R792BT)
Rear panel
Learning steering
remote input terminal
Gray/red
Bright green/red
Purple/red
Steering remote
cable (supplied)
Connect to your vehicle’s steering
remote harness. Contact your JVC
dealer for details.
JS_JVC_KD_R995BTS_K_EN_03.indd 31JS_JVC_KD_R995BTS_K_EN_03.indd 31 7/6/2017 8:41:03 AM7/6/2017 8:41:03 AM
