KD-S790

3-8

Item

Parts number Parts name Area

Electrical parts list (Main board)

Remarks

Block No. 01

C 1 NCB31EK-473X C CAPACITOR

C 2 QEKJ1HM-104Z E CAPACITOR

.10MF 20% 50V

C 4 QEKJ1AM-227Z E CAPACITOR

220MF 20% 10V

C 5 NCB31HK-103X C CAPACITOR

C 6 QEKJ1CM-106Z E CAPACITOR

10MF 20% 16V

C 7 QEKJ1CM-226Z E CAPACITOR

22MF 20% 16V

C 11 NCB31HK-103X C CAPACITOR

C 12 NCB31HK-103X C CAPACITOR

C 15 NDC31HJ-120X C CAPACITOR

C 16 NDC31HJ-7R0X C CAPACITOR

C 17 NCS31HJ-121X C CAPACITOR

C 31 QERF1HM-225Z E CAPACITOR

2.2MF 20% 50V

C 32 NCB31HK-102X C CAPACITOR

C 33 QERF1AM-227Z E CAPACITOR

220MF 20% 10V

C 34 QEKJ1HM-224Z E CAPACITOR

.22MF 20% 50V

C 41 NCB31EK-563X C CAPACITOR

C 42 NCB31EK-123X C CAPACITOR

C 43 NCS31HJ-151X C CAPACITOR

C 103 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 105 NCB31EK-333X C CAPACITOR

C 203 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 205 NCB31EK-333X C CAPACITOR

C 302 NCB31HK-822X C CAPACITOR

C 303 NCB21CK-184X C CAPACITOR

C 304 NCB31AK-224X C CAPACITOR

C 305 NCB31CK-333X C CAPACITOR

C 306 NCB31HK-562X C CAPACITOR

C 307 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 308 NCB31CK-103X C CAPACITOR

C 309 QERF1CM-476Z E CAPACITOR

47MF 20% 16V

C 310 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 346 QERF1HM-225Z E CAPACITOR

2.2MF 20% 50V

C 347 QERF1HM-225Z E CAPACITOR

2.2MF 20% 50V

C 351 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 352 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 353 NCS31HJ-391X C CAPACITOR

C 354 NCS31HJ-391X C CAPACITOR

C 355 QEKJ1CM-107Z E CAPACITOR

100MF 20% 16V

C 356 NCB31HK-223X C CAPACITOR

C 357 NCB31HK-223X C CAPACITOR

C 358 QERF1CM-476Z E CAPACITOR

47MF 20% 16V

C 359 QERF1CM-226Z E CAPACITOR

22MF 20% 16V

C 361 QERF1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 362 QERF1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 364 QERF1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 365 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 371 NCB31EK-473X C CAPACITOR

C 402 NCB31HK-822X C CAPACITOR

C 403 NCB21CK-184X C CAPACITOR

C 404 NCB31AK-224X C CAPACITOR

C 405 NCB31CK-333X C CAPACITOR

C 406 NCB31HK-562X C CAPACITOR

C 446 QEKJ1HM-225Z E CAPACITOR

2.2MF 20% 50V

C 447 QEKJ1HM-225Z E CAPACITOR

2.2MF 20% 50V

C 451 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 452 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 453 NCS31HJ-391X C CAPACITOR

C 454 NCS31HJ-391X C CAPACITOR

C 501 NCB31HK-103X C CAPACITOR

C 502 NCB31HK-103X C CAPACITOR

C 503 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 504 NCB31HK-103X C CAPACITOR

C 505 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 507 NCB31HK-682X C CAPACITOR

C 508 NCB31HK-103X C CAPACITOR

C 509 QERF1AM-107Z E CAPACITOR

100MF 20% 10V

C 510 NCB31CK-104X C CAPACITOR

C 511 NCB31CK-104X C CAPACITOR

C 512 NDC31HJ-820X C CAPACITOR

C 513 NCB31HK-103X C CAPACITOR

C 514 NDC31HJ-5R0X C CAPACITOR

C 521 NCB31HK-103X C CAPACITOR

C 522 QERF1AM-107Z E CAPACITOR

100MF 20% 10V

C 523 NDC31HJ-470X C CAPACITOR

C 524 NCB31HK-153X C CAPACITOR

C 525 NCB31HK-103X C CAPACITOR

C 526 NCB31HK-272X C CAPACITOR

C 527 NCB31HK-103X C CAPACITOR

C 528 NCB31EK-333X C CAPACITOR

C 529 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 530 NCB31EK-333X C CAPACITOR

C 531 NCB31EK-473X C CAPACITOR

C 533 NCS31HJ-471X C CAPACITOR

C 534 NCS31HJ-471X C CAPACITOR

C 535 NCB31EK-473X C CAPACITOR

C 536 NCB31EK-473X C CAPACITOR

C 537 NCB31EK-473X C CAPACITOR

C 538 NCB31EK-473X C CAPACITOR

C 539 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 540 NCB31HK-103X C CAPACITOR

C 541 NCB31HK-103X C CAPACITOR

C 545 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 546 NCS31HJ-101X C CAPACITOR

C 547 NCB31CK-104X C CAPACITOR

C 548 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 549 NCB31HK-103X C CAPACITOR

C 550 QERF1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 551 QERF1AM-107Z E CAPACITOR

100MF 20% 10V

C 552 NCB31HK-103X C CAPACITOR

C 553 NDC31HJ-180X C.CAPACITOR

C 554 NDC31HJ-180X C.CAPACITOR

C 555 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 556 NCB31HK-103X C CAPACITOR

C 561 QERF0JM-476Z E CAPACITOR

47MF 20% 6.3V

C 562 NCB31HK-103X C CAPACITOR

C 563 QERF1AM-107Z E CAPACITOR

100MF 20% 10V

C 564 NCB31EK-473X C CAPACITOR

C 565 NCB31EK-473X C CAPACITOR

C 566 NCB31EK-473X C CAPACITOR

C 567 NCB31EK-473X C CAPACITOR

C 581 NCS31HJ-821X C CAPACITOR

C 582 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 583 NCS31HJ-121X C CAPACITOR

C 584 NCS31HJ-821X C CAPACITOR

C 585 QEKJ0JM-476Z E CAPACITOR

47MF 20% 6.3V

C 587 NCB31EK-473X C CAPACITOR

C 588 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 589 NCB31HK-182X C CAPACITOR

C 591 NCS31HJ-821X C CAPACITOR

C 592 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 593 NCS31HJ-121X C CAPACITOR

C 594 NCS31HJ-821X C CAPACITOR

C 595 QEKJ0JM-476Z E CAPACITOR

47MF 20% 6.3V

C 596 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 598 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 599 NDC31HJ-221X C CAPACITOR

C 698 NCB21CK-474X C CAPACITOR

C 699 NCB31EK-104X C CAPACITOR

C 702 NCB31EK-104X C CAPACITOR

C 703 NCB31EK-104X C CAPACITOR

C 705 NCS31HJ-220X C CAPACITOR

C 706 NCS31HJ-220X C CAPACITOR

Item

Parts number Parts name Area

Remarks
