KD-S790
3-9
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 707 QEKJ0JM-227Z E CAPACITOR
220MF 20% 6.3V
C 708 QEKJ0JM-227Z E CAPACITOR
220MF 20% 6.3V
C 709 NCB31EK-473X C CAPACITOR
C 710 NCB31EK-104X C CAPACITOR
C 711 NCB31EK-473X C CAPACITOR
C 712 NCB31EK-103X C CAPACITOR
C 713 NCB31EK-103X C CAPACITOR
C 714 NCB31EK-104X C CAPACITOR
C 715 NCB31EK-104X C CAPACITOR
C 716 NCB31HK-331X C CAPACITOR
C 951 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 952 NCB31EK-473X C CAPACITOR
C 953 QERF1CM-226Z E CAPACITOR
22MF 20% 16V
C 954 QEKJ1HM-224Z E CAPACITOR
.22MF 20% 50V
C 960 QEZ0622-338 E CAPACITOR
3300MF
C 961 QEKJ1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 962 QEKJ1CM-476Z E CAPACITOR
47MF 20% 16V
C 963 QEKJ1CM-106Z E CAPACITOR
10MF 20% 16V
C 964 QEKJ1CM-106Z E CAPACITOR
10MF 20% 16V
C 965 QEKJ1CM-226Z E CAPACITOR
22MF 20% 16V
C 966 NCB31AK-474X C CAPACITOR
C 967 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 968 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 969 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 970 NCB31EK-104X C CAPACITOR
C 975 NCB31EK-103X C CAPACITOR
C 976 QEKJ0JM-107Z E CAPACITOR
100MF 20% 6.3V
C 977 QEKJ1CM-107Z E CAPACITOR
100MF 20% 16V
C 981 NCB31CK-104X C CAPACITOR
C 982 NCB31CK-104X C CAPACITOR
C 983 NCB31CK-104X C CAPACITOR
C 984 NCB31CK-104X C CAPACITOR
C 991 NCS31HJ-101X C CAPACITOR
C 992 NCS31HJ-101X C CAPACITOR
C 993 NCS31HJ-101X C CAPACITOR
C 994 NCS31HJ-101X C CAPACITOR
C 995 NCS31HJ-101X C CAPACITOR
C 996 NCS31HJ-101X C CAPACITOR
C 997 NCS31HJ-101X C CAPACITOR
C 998 NCS31HJ-101X C CAPACITOR
CN501 QGB2027M4-22S CONNECTOR
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0611-001 CAR CONNECTOR
D 1 1SS355-X DIODE
D 2 1SS355-X DIODE
D 3 1SS355-X DIODE
D 4 1SS355-X DIODE
D 7 1SS355-X DIODE
D 301 1SS355-X DIODE
D 302 1SS355-X DIODE
D 351 1SS355-X DIODE
D 372 1SS355-X DIODE
D 472 1SS355-X DIODE
D 561 1A3G-T1 DIODE
D 701 UDZS6.2B-X SI DIODE
D 702 UDZS6.2B-X SI DIODE
D 703 UDZS6.2B-X SI DIODE
D 704 UDZS6.2B-X SI DIODE
D 705 UDZS6.2B-X SI DIODE
D 706 UDZS6.2B-X SI DIODE
D 707 UDZS6.2B-X SI DIODE
D 708 UDZS6.2B-X SI DIODE
D 709 UDZS6.2B-X SI DIODE
D 710 UDZS6.2B-X SI DIODE
D 711 UDZS6.2B-X SI DIODE
D 712 UDZS6.2B-X SI DIODE
D 713 LNJ308G81/1-3/X LED
D 714 LNJ308G81/1-3/X LED
D 715 LNJ308G81/1-3/X LED
D 951 RB160M-30-X SB DIODE
D 952 1SS355-X DIODE
D 953 UDZS5.1B-X Z DIODE
D 960 1N5401-F64 DIODE
D 961 1SS355-X DIODE
D 962 RB160M-30-X SB DIODE
D 963 RB160M-30-X SB DIODE
D 976 1SS355-X DIODE
D 977 UDZS11B-X Z.DIODE
IC301 TEA6320T-X IC
IC351 LA47505 IC
IC501 TA2157FN-X IC
IC521 TC94A14FA IC
IC561 LA6579H-X IC
IC571 NJM4565M-WE IC
IC701 UPD178078GF-594 I.C(MICRO-COMP)
IC961 HA13164A IC
J 1 QNB0100-002 ANT TERMINAL
J 931 QNN0519-001 PIN JACK
L 1 QQL244J-4R7Z INDUCTOR
L 521 QQL244J-4R7Z INDUCTOR
L 522 QQL244J-4R7Z INDUCTOR
L 523 QQL244J-470Z INDUCTOR
L 524 QQL244J-4R7Z INDUCTOR
L 701 QQL244J-4R7Z INDUCTOR
L 702 QQL244J-4R7Z INDUCTOR
L 961 QQR0703-001 CHOKE COIL
2 UN2211-X TRANSISTOR
5 2SB709A/R/-X TRANSISTOR
6 2SB624/4/-X TRANSISTOR
7 UN2211-X TRANSISTOR
8 UN2211-X TRANSISTOR
31 2SD601A/R/-X TRANSISTOR
32 2SD601A/R/-X TRANSISTOR
41 2SC3661-X TRANSISTOR
42 2SC3661-X TRANSISTOR
351 UN2211-X TRANSISTOR
372 2SD1781K/QR/-X TRANSISTOR
472 2SD1781K/QR/-X TRANSISTOR
501 2SB1241/QR/-T TRANSISTOR
521 UN2111-X TRANSISTOR
522 UN2211-X TRANSISTOR
561 2SB1322/RS/-T TRANSISTOR
951 2SD601A/R/-X TRANSISTOR
963 2SB709A/R/-X TRANSISTOR
964 UN2211-X TRANSISTOR
976 UN2111-X TRANSISTOR
977 UN2111-X TRANSISTOR
R 1 NRSA63J-680X MG RESISTOR
R 2 NRSA63J-223X MG RESISTOR
R 3 NRSA63J-822X MG RESISTOR
R 4 NRSA63J-473X MG RESISTOR
R 5 NRSA02J-332X MG RESISTOR
R 6 NRSA63J-473X MG RESISTOR
R 7 NRSA63J-473X MG RESISTOR
R 8 NRSA63J-472X MG RESISTOR
R 404 NRSA63J-472X MG RESISTOR
R 446 NRSA63J-473X MG RESISTOR
R 447 NRSA63J-473X MG RESISTOR
R 451 NRSA63J-273X MG RESISTOR
R 452 NRSA63J-273X MG RESISTOR
R 472 NRSA02J-821X MG RESISTOR
R 474 NRSA63J-222X MG RESISTOR
