KD-S790
3-11
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
S 703 QSQ1A11-V06Z TACT SWITCH
RESET
TU 1 QAU0281-001 TUNER PACK
X 521 QAX0741-001Z C RESONATOR
X 701 QAX0406-001Z CRYSTAL
R 9 NRSA63J-473X MG RESISTOR
R 11 NRSA02J-0R0X MG RESISTOR
R 12 NRS181J-150X MG RESISTOR
R 13 NRS181J-150X MG RESISTOR
R 14 NRSA63J-103X MG RESISTOR
R 15 NRSA63J-103X MG RESISTOR
R 31 NRSA63J-152X MG RESISTOR
R 32 NRSA63J-102X MG RESISTOR
R 33 NRSA63J-103X MG RESISTOR
R 34 NRSA02J-330X MG RESISTOR
R 35 NRSA63J-102X MG RESISTOR
R 41 NRSA63J-102X MG RESISTOR
R 42 NRSA63J-392X MG RESISTOR
R 43 NRSA02J-102X MG RESISTOR
R 45 NRSA63J-102X MG RESISTOR
R 101 NRSA63J-272X MG RESISTOR
R 102 NRSA63J-432X MG RESISTOR
R 201 NRSA63J-272X MG RESISTOR
R 202 NRSA63J-432X MG RESISTOR
R 301 NRSA63J-224X MG RESISTOR
R 302 NRSA63J-223X MG RESISTOR
R 303 NRSA63J-222X MG RESISTOR
R 304 NRSA63J-472X MG RESISTOR
R 346 NRSA63J-473X MG RESISTOR
R 347 NRSA63J-473X MG RESISTOR
R 351 NRSA63J-273X MG RESISTOR
R 352 NRSA63J-273X MG RESISTOR
R 356 NRSA02J-103X MG RESISTOR
R 357 NRSA63J-103X MG RESISTOR
R 372 NRSA02J-821X MG RESISTOR
R 374 NRSA63J-222X MG RESISTOR
R 376 NRSA02J-101X MG RESISTOR
R 401 NRSA63J-224X MG RESISTOR
R 402 NRSA63J-223X MG RESISTOR
R 403 NRSA63J-222X MG RESISTOR
