KD-S790
3-12
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
C 601 NCB31HK-223X C CAPACITOR
C 602 NCS31HJ-681X C CAPACITOR
C 603 NBE20JM-106X TS E CAP SVB20J
C 611 NCB31HK-123X C CAPACITOR
C 612 NBE20JM-475X TS E CAPACITOR
CN601 NNZ0087-001 CAR CONNECTOR
D 601 SML-310VT/JK/-X LED
D 602 SML-310VT/JK/-X LED
D 603 SML-310VT/JK/-X LED
D 604 SML-310VT/JK/-X LED
D 605 SML-310VT/JK/-X LED
D 606 SML-310VT/JK/-X LED
D 607 SML-310VT/JK/-X LED
D 609 SML-310VT/JK/-X LED
D 610 SML-310VT/JK/-X LED
D 611 SML-310VT/JK/-X LED
D 613 SML-310VT/JK/-X LED
D 614 SML-310VT/JK/-X LED
D 615 SML-310VT/JK/-X LED
D 616 SML-310VT/JK/-X LED
D 617 SML-310VT/JK/-X LED
D 619 SML-310VT/JK/-X LED
D 620 SML-310VT/JK/-X LED
D 621 SML-310VT/JK/-X LED
D 622 SML-310VT/JK/-X LED
D 623 SML-310VT/JK/-X LED
D 624 SML-310VT/JK/-X LED
D 625 SML-310LT/MN/-X LED
D 641 UDZS5.1B-X Z DIODE
D 643 1SS355-X DIODE
D 644 NSPW310BS/BRS/ LED
D 645 NSPW310BS/BRS/ LED
D 646 UDZS6.2B-X SI DIODE
EN601 QSW0793-001 ROTARY ENCODER
IC601 PT6523LQ IC
IC602 RPM6938-SV4 IC
R 601 NRSA63J-821X MG RESISTOR
R 602 NRSA63J-821X MG RESISTOR
R 603 NRSA63J-122X MG RESISTOR
R 604 NRSA63J-182X MG RESISTOR
R 605 NRSA63J-272X MG RESISTOR
R 606 NRSA63J-821X MG RESISTOR
R 607 NRSA63J-821X MG RESISTOR
R 608 NRSA63J-122X MG RESISTOR
R 609 NRSA63J-182X MG RESISTOR
R 610 NRSA63J-272X MG RESISTOR
R 612 NRSA63J-821X MG RESISTOR
R 613 NRSA63J-821X MG RESISTOR
R 614 NRSA63J-122X MG RESISTOR
R 615 NRSA63J-392X MG RESISTOR
R 631 NRS181J-821X MG RESISTOR
R 632 NRSA02J-561X MG RESISTOR
R 633 NRSA02J-561X MG RESISTOR
R 634 NRSA02J-561X MG RESISTOR
R 635 NRSA02J-561X MG RESISTOR
R 636 NRSA02J-821X MG RESISTOR
R 637 NRSA02J-821X MG RESISTOR
R 638 NRSA02J-511X MG RESISTOR
R 639 NRSA02J-511X MG RESISTOR
R 640 NRSA02J-511X MG RESISTOR
R 641 NRSA02J-511X MG RESISTOR
R 642 NRSA02J-821X MG RESISTOR
R 643 NRSA02J-821X MG RESISTOR
R 644 NRSA02J-561X MG RESISTOR
R 645 NRSA02J-561X MG RESISTOR
R 646 NRSA02J-122X MG RESISTOR
R 647 NRSA02J-122X MG RESISTOR
R 648 NRSA02J-122X MG RESISTOR
R 649 NRSA02J-122X MG RESISTOR
R 651 NRSA63J-222X MG RESISTOR
R 652 NRSA63J-222X MG RESISTOR
R 653 NRSA63J-103X MG RESISTOR
R 654 NRSA63J-103X MG RESISTOR
R 655 NRSA63J-103X MG RESISTOR
R 656 NRSA63J-103X MG RESISTOR
R 657 NRSA63J-513X MG RESISTOR
R 658 NRSA63J-184X MG RESISTOR
R 659 NRS181J-391X MG RESISTOR
R 660 NRS181J-391X MG RESISTOR
R 661 NRSA63J-103X MG RESISTOR
R 662 NRSA63J-471X MG RESISTOR
R 672 NRS181J-0R0X MG RESISTOR
R 681 NRSA63J-101X MG RESISTOR
S 601 NSW0066-001X TACT SW
S 602 NSW0066-001X TACT SW
S 603 NSW0066-001X TACT SW
S 604 NSW0066-001X TACT SW
S 605 NSW0066-001X TACT SW
S 606 NSW0066-001X TACT SW
S 607 NSW0066-001X TACT SW
S 608 NSW0066-001X TACT SW
S 609 NSW0066-001X TACT SW
S 610 NSW0066-001X TACT SW
S 611 NSW0066-001X TACT SW
S 612 NSW0066-001X TACT SW
S 613 NSW0066-001X TACT SW
S 614 NSW0066-001X TACT SW
S 615 NSW0066-001X TACT SW
S 616 NSW0066-001X TACT SW
S 617 NSW0066-001X TACT SW
