JVC KD-S7R Service Manual

KD-S7R
3-3
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 ---------------
CD MECHA
1
2 FSJC1029-404
TOP CHASSIS
1
3 FSMH3001-202
SIDE PANEL
1
4 FSKM3011-002
BOTTOM COVER
1
5 FSMA3004-003
INSULATOR
1
6 QYSDST2604Z
SCREW
3
CHASSIS+MECHA B
7 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PA
8 QYSDST2604Z
SCREW
3
CHASSIS+REAR BK
9 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PW
10 FSKZ4005-001
SCREW
1
SIDE PANEL+IC B
11 FSJC2013-002
FRONT CHASSIS
1
12 FSKS3010-001
LOCK LEVER
1
13 FSKW4005-003
TORSION SPRING
1
FOR LOCK LEVEL
14 FSXP3026-002
RLS KNOB
1
15 FSKW3002-015
COMP.SPRING
1
16 FSPK3009-001
BLIND
1
17 FSJC1057-002
FRONT PANEL
1
18 FSJD3023-00L
FINDER ASSY
1
19 FSXP2035-102
PRESET BUTTON
1
1-6,TP/RDS,PTY
20 FSXP3053-002
POWER BUTTON
1
21 FSXP3054-002
EJECT BUTTON
1
22 FSXP2034-034
D.FUNC BUTTON
1
CD/FM/AM
23 FSXP4005-019
BBE BUTTON
1
SCM
24 FSXP3068-002
PUSH BUTTON
1
DISP,MO/RND
25 FSXP2044-001
COMBO BUTTON
1
26 FSXP3055-001
DETACH BUTTON
1
27 FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTT
28 FSJK3026-001
CD LENS
1
29 FSJC1043-002
REAR COVER
1
30 VKZ4777-001
MINI SCREW
4
FRONT+REAR
31 GE30249-002A
NAME PLATE
1
32 VMA4652-001SS
EARTH PLATE
1
33 QMFZ021-100-J1
FUSE
A
1
34 QLD0126-001
LCD MODULE
1
LCD1
35 FSYH3023-001
LCD CASE
1
36 FSJK3035-001
LCD LENS
1
37 FSKS3022-002
LENS CASE
1
38 FSYH4078-001
LIGHT SHEET
1
39 QNZ0442-001
RUBBER CONNE
1
40 FSKM3012-012
REAR BRACKET
1
41 FSKL4018-00B
IC BRACKET
1
42 FSKL4014-001
HEAT SINK
1
43 FSKL4015-002
REG BRACKET
1
44 QYSDST2606Z
SCREW
1
FOR ANT
45 QYSDST2606Z
SCREW
1
16P & TR BRACK
46 QYSDSF3006Z
SCREW
1
LINE OUT
