JVC KD-S7R Service Manual

KD-S7R
3-11
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
C 601 NCB21HK-223X C CAPACITOR
C 602 NCS21HJ-681X C CAPACITOR
C 603 NBE20JM-106X TS E CAP SVB20J
CJ601 VMC0335-001 CONNECTOR
D 601 SML-310DT/KL/-X LED
D 602 SML-310DT/KL/-X LED
D 603 SML-310DT/KL/-X LED
D 604 SML-310DT/KL/-X LED
D 605 SML-310DT/KL/-X LED
D 606 SML-310DT/KL/-X LED
D 607 SML-310DT/KL/-X LED
D 608 SML-310DT/KL/-X LED
D 609 SML-310DT/KL/-X LED
D 610 SML-310DT/KL/-X LED
D 611 SML-310DT/KL/-X LED
D 612 SML-310DT/KL/-X LED
D 613 SML-310DT/KL/-X LED
D 614 SML-310DT/KL/-X LED
D 615 SML-310DT/KL/-X LED
D 616 SML-310DT/KL/-X LED
D 617 SML-310DT/KL/-X LED
D 618 SML-310DT/KL/-X LED
D 619 SML-310DT/KL/-X LED
D 620 SML-310DT/KL/-X LED
D 621 SML-310LT/MN/-X LED POWER LED
D 641 MA3047/M/-X ZENER DIODE
D 642 MA152WK-X SI DIODE
IC601 LC75823W IC
PL601 QLL0075-001 PILOT LAMP
PL602 QLL0075-001 PILOT LAMP
R 601 NRSA02J-821X MG RESISTOR
R 602 NRSA02J-821X MG RESISTOR
R 603 NRSA02J-122X MG RESISTOR
R 604 NRSA02J-182X MG RESISTOR
R 605 NRSA02J-272X MG RESISTOR
R 606 NRSA02J-821X MG RESISTOR
R 607 NRSA02J-821X MG RESISTOR
R 608 NRSA02J-122X MG RESISTOR
R 609 NRSA02J-182X MG RESISTOR
R 610 NRSA02J-272X MG RESISTOR
R 611 NRSA02J-392X MG RESISTOR
R 612 NRSA02J-103X MG RESISTOR
R 613 NRSA02J-821X MG RESISTOR
R 614 NRSA02J-821X MG RESISTOR
R 615 NRSA02J-122X MG RESISTOR
R 616 NRSA02J-182X MG RESISTOR
R 617 NRSA02J-272X MG RESISTOR
R 618 NRSA02J-392X MG RESISTOR
R 631 NRSA02J-821X MG RESISTOR
R 632 NRSA02J-271X MG RESISTOR
R 633 NRSA02J-271X MG RESISTOR
R 634 NRSA02J-271X MG RESISTOR
R 635 NRSA02J-271X MG RESISTOR
R 636 NRSA02J-271X MG RESISTOR
R 637 NRSA02J-271X MG RESISTOR
R 638 NRSA02J-271X MG RESISTOR
R 639 NRSA02J-271X MG RESISTOR
R 640 NRSA02J-271X MG RESISTOR
R 641 NRSA02J-271X MG RESISTOR
R 651 NRSA02J-222X MG RESISTOR
R 652 NRSA02J-222X MG RESISTOR
R 653 NRSA02J-103X MG RESISTOR
R 654 NRSA02J-103X MG RESISTOR
R 655 NRSA02J-103X MG RESISTOR
R 656 NRSA02J-103X MG RESISTOR
R 657 NRSA02J-513X MG RESISTOR
R 658 NRSA02J-184X MG RESISTOR
S 601 NSW0124-001X TACT SWITCH POWER
S 602 NSW0124-001X TACT SWITCH VOL UP
S 603 NSW0124-001X TACT SWITCH VOL DOWN
S 604 NSW0124-001X TACT SWITCH LOUD
S 605 NSW0124-001X TACT SWITCH MO
S 606 NSW0124-001X TACT SWITCH DOWN
S 607 NSW0124-001X TACT SWITCH SELECT
S 608 NSW0124-001X TACT SWITCH UP
S 609 NSW0124-001X TACT SWITCH 1
S 610 NSW0124-001X TACT SWITCH 2
S 611 NSW0124-001X TACT SWITCH 3
S 612 NSW0124-001X TACT SWITCH 4
S 613 NSW0124-001X TACT SWITCH 5
S 614 NSW0124-001X TACT SWITCH EJECT
S 615 NSW0124-001X TACT SWITCH 6
S 616 NSW0124-001X TACT SWITCH DISPLAY
S 617 NSW0124-001X TACT SWITCH SCAN
S 618 NSW0124-001X TACT SWITCH SOUND
S 619 NSW0124-001X TACT SWITCH AM
S 620 NSW0124-001X TACT SWITCH FM
S 621 NSW0124-001X TACT SWITCH CD
Item
Parts number Parts name Area
Remarks
A
