JVC KD-S7R Service Manual

KD-S7R
3-13
Item
Parts number Parts name Area
A
Parts list (Packing )
Q'ty
Description
Block No. M3MM
P 1 GE30123-040A
PACKING CASE
1
P 2 GE10008-001A
CUSHION
2
P 3 QPC03004315P
POLY BAG
1
SET
P 4 FSPG4002-001
POLY BAG
EX
1
INST.BOOK
FSPG4002-001
POLY BAG
E
2
INST.BOOK
P 5 QPA00801205
POLY BAG
1
SCREW
P 6 FSYH4036-068
SHEET
1
P 7 QPA01003003
POLY BAG
1
Item
Parts number Parts name Area
A
Parts list (Accessories)
Q'ty
Description
Block No. M4MM
A 1 GET0042-002A
INST BOOK
E
1
FIN,ITA,SPA,SWE
A 2 GET0042-001A
INST BOOK
1
ENG,FRE,GER,DUT
A 3 GET0042-003A
INSTALL MANUAL
1
ENG,GER,FRE
GET0042-004A
INSTALL MANUAL
1
DUT,SPA,ITA
GET0042-005A
INSTALL MANUAL
E
1
SWE,FIN
A 4 BT-54013-1
WARRANTY CARD
1
A 5 LV40978-001A
CAUTION SHEET
1
A 6 VKZ4027-202
PLUG NUT
1
A 7 VKH4871-001SS
MOUNT BOLT
1
A 8 VKZ4328-001
LOCK NUT
1
FOR M5
A 9 WNS5000Z
WASHER
1
A 10 FSKL4010-002
HOOK
2
A 11 FSJB3001-30C
HARD CASE
1
A 12 FSKM2004-202
MOUNTING SLEEVE
1
A 13 QAM0175-001
POWER CORD
1
A 14 FSJD2034-001
TRIM PLATE
1
KIT KDGS717K-SCREW1
SCREW PARTS KIT
1
A6-A10
