Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 591 NCS31HJ-821X C CAPACITOR
C 592 QEKJ1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 593 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 594 NCS31HJ-121X C CAPACITOR
C 595 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 701 NDC31HJ-220X C CAPACITOR
C 702 NDC31HJ-220X C CAPACITOR
C 703 NCB31EK-104X C CAPACITOR
C 704 NCB31EK-104X C CAPACITOR
C 706 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 707 NCB31HK-103X C CAPACITOR
C 708 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 713 NCB31HK-471X C CAPACITOR
C 718 NCB31HK-103X C CAPACITOR
C 719 NCB31EK-104X C CAPACITOR
C 720 NCB31EK-104X C CAPACITOR
C 721 NCB31EK-104X C CAPACITOR
C 770 NCB31HK-103X C CAPACITOR
C 776 NCB31HK-103X C CAPACITOR
C 781 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 782 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 783 NCB31EK-823X C CAPACITOR
C 891 NCB31EK-473X C CAPACITOR
C 901 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 902 NCB31EK-104X C CAPACITOR
C 903 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V
C 904 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 905 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 907 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 908 QEZ0338-228 E CAPACITOR 2200MF
C 909 NCB31EK-104X C CAPACITOR
C 911 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 912 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 913 QEKJ1CM-107Z E CAPACITOR 100MF 20% 16V
C 914 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 915 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 933 NCB31EK-103X C CAPACITOR
CN501 QGB2027M1-26S CONNECTOR
CP601 VMC0334-001 CONNECTOR
CP961 QNZ0112-001 CAR CONNECTOR
D 1 1SS133-T1 SI DIODE
D 2 1SS133-T1 SI DIODE
D 3 1SS355-X DIODE
D 4 1SS355-X DIODE
D 161 1SS355-X DIODE
D 162 1SS355-X DIODE
D 182 1SS355-X DIODE
D 241 1SS133-T1 SI DIODE
D 242 1SS133-T1 SI DIODE
D 321 1SS355-X DIODE
D 331 1SS355-X DIODE
D 341 1SS355-X DIODE
D 351 1SS355-X DIODE
D 501 DSK10C-T1 DIODE
D 701 UDZS5.6B-X ZENER DIODE
D 702 UDZS5.6B-X ZENER DIODE
D 703 UDZS5.6B-X ZENER DIODE
D 704 UDZS5.6B-X ZENER DIODE
D 705 UDZS5.6B-X ZENER DIODE
D 706 UDZS5.6B-X ZENER DIODE
D 707 UDZS5.6B-X ZENER DIODE
D 781 1SS355-X DIODE
D 782 1SS133-T1 SI DIODE
D 784 UDZ11B-X ZENER DIODE
D 891 1SS355-X DIODE
D 892 1SS355-X DIODE
D 901 1SS355-X DIODE
D 910 CRS03-W SB DIODE
D 911 1N5401-TU-15 DIODE
D 912 CRS03-W SB DIODE
IC 71 SAA6579T-X IC
IC161 TEA6320T-X IC
IC301 LA4743K IC
IC501 LA6567H-X IC
IC521 TA2109F-X IC
IC541 TC9462F IC
IC581 NJM4565M-WE IC
IC701 UPD178078GF-561 IC
IC961 HA13164A IC
J 1 QNB0100-002 ANT TERMINAL
J 301 QNN0175-001 PIN JACK
L 1 QQL244J-4R7Z INDUCTOR
L 541 QQL244J-4R7Z INDUCTOR
L 542 QQL244J-4R7Z INDUCTOR
L 701 QQL244J-4R7Z INDUCTOR
L 961 QQR0703-001 CHOKE COIL
Q
1 UN2211-X TRANSISTOR
Q
2 2SD601A/R/-X TRANSISTOR
Q
3 UN2111-X TRANSISTOR
Q
4 2SB709A/R/-X TRANSISTOR
Q
5 2SB815/7/-X TRANSISTOR
Q
7 UN2211-X TRANSISTOR
Q
31 2SD601A/R/-X TRANSISTOR
Q
32 2SD601A/R/-X TRANSISTOR
Q
41 2SD601A/R/-X TRANSISTOR
Q
42 2SC3661-X TRANSISTOR
Q
43 UN2211-X TRANSISTOR
Q
51 2SD601A/R/-X TRANSISTOR
Q
52 2SD601A/R/-X TRANSISTOR
Q
53 UN2211-X TRANSISTOR
Q
161 2SD601A/R/-X TRANSISTOR
Q
162 UN2111-X TRANSISTOR
Q
174 UN2111-X TRANSISTOR
Q
181 2SD601A/R/-X TRANSISTOR
Q
241 2SD601A/R/-X TRANSISTOR
Q
321 2SD1048/6-7/-X TRANSISTOR
Q
331 2SD1048/6-7/-X TRANSISTOR
Q
341 2SD1048/6-7/-X TRANSISTOR
Q
351 2SD1048/6-7/-X TRANSISTOR
Q
501 2SB1322/RS/-T TRANSISTOR
Q
521 2SB1322/RS/-T TRANSISTOR
Q
781 UN2111-X TRANSISTOR
Q
782 UN2211-X TRANSISTOR
Q
783 UN2111-X TRANSISTOR
Q
891 UN2211-X TRANSISTOR
Q
976 UN2211-X TRANSISTOR
Q
977 2SB709A/R/-X TRANSISTOR
R 1 NRSA63J-8R2X MG RESISTOR
R 2 NRSA63J-102X MG RESISTOR
R 3 NRSA63J-102X MG RESISTOR
R 4 NRSA63J-223X MG RESISTOR
R 5 NRSA63J-472X MG RESISTOR
R 6 NRSA63J-473X MG RESISTOR
R 7 NRSA63J-472X MG RESISTOR
R 8 NRSA63J-473X MG RESISTOR
R 9 NRSA63J-332X MG RESISTOR
