KD-S871R
3-11
Item
Parts number Parts name Ar
e
a
Electrical parts list (Front board)
Remarks
Block No. 02
A
C 651 NCB31HK-223X C CAPACITOR
C 652 NCS31HJ-681X C CAPACITOR
C 653 NBE20JM-106X TS E CAP SVB20J
C 661 NCS31HJ-101X C CAPACITOR
C 662 NBE20JM-225X TS E CAPACITOR
C 663 NCS31HJ-101X C CAPACITOR
C 664 NBE20JM-225X TS E CAPACITOR
C 671 NCB31HK-123X C CAPACITOR
C 672 NBE20JM-475X TS E CAPACITOR
CJ601 VMC0335-001 CONNECTOR
D 601 SML-310VT/JK/-X LED
D 602 SML-310VT/JK/-X LED
D 603 SML-310VT/JK/-X LED
D 604 SML-310VT/JK/-X LED
D 605 SML-310VT/JK/-X LED
D 606 SML-310VT/JK/-X LED
D 607 SML-310VT/JK/-X LED
D 608 SML-310VT/JK/-X LED
D 609 SML-310VT/JK/-X LED
D 610 SML-310VT/JK/-X LED
D 611 SML-310VT/JK/-X LED
D 612 SML-310VT/JK/-X LED
D 613 SML-310VT/JK/-X LED
D 614 LT1F67AF-W LED
D 615 SML-310VT/JK/-X LED
D 616 SML-310VT/JK/-X LED
D 617 SML-310VT/JK/-X LED
D 618 SML-310VT/JK/-X LED
D 620 UDZS5.1B-X ZENER DIODE
D 621 SML-310VT/JK/-X LED
D 625 SML-310LT/MN/-X LED
D 651 UDZS5.1B-X ZENER DIODE
D 652 1SS355-X DIODE
D 653 1SS355-X DIODE
D 661 UDZS6.2B-X SI DIODE
D 662 SMLU12E16W LED
D 664 UDZS6.2B-X SI DIODE
D 671 UDZS6.2B-X SI DIODE
IC601 LC75823W IC
IC602 RPM6938-SV4 IC
Q
661 2SD601A/R/-X TRANSISTOR
Q
662 2SD601A/R/-X TRANSISTOR
Q
663 2SD601A/R/-X TRANSISTOR
Q
664 2SD601A/R/-X TRANSISTOR
R 601 NRSA63J-821X MG RESISTOR
R 602 NRSA63J-821X MG RESISTOR
R 603 NRSA63J-122X MG RESISTOR
R 604 NRSA63J-182X MG RESISTOR
R 605 NRSA63J-272X MG RESISTOR
R 606 NRSA63J-821X MG RESISTOR
R 607 NRSA63J-821X MG RESISTOR
R 608 NRSA63J-122X MG RESISTOR
R 609 NRSA63J-182X MG RESISTOR
R 610 NRSA63J-272X MG RESISTOR
R 611 NRSA63J-392X MG RESISTOR
R 612 NRSA63J-821X MG RESISTOR
R 613 NRSA63J-821X MG RESISTOR
R 614 NRSA63J-122X MG RESISTOR
R 615 NRSA63J-182X MG RESISTOR
R 616 NRSA63J-272X MG RESISTOR
R 617 NRSA63J-392X MG RESISTOR
R 631 NRSA02J-821X MG RESISTOR
R 632 NRSA02J-222X MG RESISTOR
R 633 NRSA02J-222X MG RESISTOR
R 634 NRSA02J-102X MG RESISTOR
R 635 NRSA02J-102X MG RESISTOR
R 636 NRSA02J-122X MG RESISTOR
R 637 NRSA02J-122X MG RESISTOR
R 638 NRSA02J-391X MG RESISTOR
R 639 NRSA02J-391X MG RESISTOR
R 640 NRSA02J-391X MG RESISTOR
R 641 NRSA02J-391X MG RESISTOR
R 642 NRSA02J-681X MG RESISTOR
R 643 NRSA02J-681X MG RESISTOR
R 644 NRSA02J-102X MG RESISTOR
R 645 NRSA02J-102X MG RESISTOR
R 651 NRSA63J-222X MG RESISTOR
R 652 NRSA63J-222X MG RESISTOR
R 653 NRSA63J-103X MG RESISTOR
R 654 NRSA63J-103X MG RESISTOR
R 655 NRSA63J-103X MG RESISTOR
R 656 NRSA63J-103X MG RESISTOR
R 657 NRSA63J-513X MG RESISTOR
R 658 NRSA63J-184X MG RESISTOR
R 662 NRSA02J-681X MG RESISTOR
R 663 NRSA02J-681X MG RESISTOR
R 664 NRSA02J-561X MG RESISTOR
R 665 NRSA02J-561X MG RESISTOR
R 671 NRSA63J-103X MG RESISTOR
R 672 NRSA63J-471X MG RESISTOR
R 680 NRSA02J-102X MG RESISTOR
R 681 NRSA02J-102X MG RESISTOR
S 601 NSW0066-001X TACT SWITCH POWER
S 602 NSW0066-001X TACT SWITCH VOL+
S 603 NSW0066-001X TACT SWITCH VOL-
S 604 NSW0066-001X TACT SWITCH LOUD
S 605 NSW0066-001X TACT SWITCH DISP
S 606 NSW0066-001X TACT SWITCH 1
S 607 NSW0066-001X TACT SWITCH SEL
S 608 NSW0066-001X TACT SWITCH 2
S 609 NSW0066-001X TACT SWITCH 3
S 610 NSW0066-001X TACT SWITCH 4
S 611 NSW0066-001X TACT SWITCH 5
S 612 NSW0066-001X TACT SWITCH EJECT
S 613 NSW0066-001X TACT SWITCH
S 614 NSW0066-001X TACT SWITCH 6
S 615 NSW0066-001X TACT SWITCH MO/RND
S 616 NSW0066-001X TACT SWITCH SCM
S 617 NSW0066-001X TACT SWITCH
S 618 NSW0066-001X TACT SWITCH AM
S 619 NSW0066-001X TACT SWITCH FM
S 620 NSW0066-001X TACT SWITCH CD
Item
Parts number Parts name Ar
e
a
Remarks
A
