KD-SC800R
(No.49820)1-7
2.1.8
Re
moving the front boar
d
(See Figs.11 to 13)
•
Prior to performing the fol
lowin
g procedure, remove the front
panel assembly.
(1)
Remove the four screws
K
on the back side of
the front
panel assembly.
(2)
Release the ten joints
g
.
(3)
Take out the front board.
Fig.11
Fig.12
Fig.13
KK
K
Joint
g
Joint
g
Joint
g
Joint
g
Front board
