JVC KD-SH9101 Service Manual

(No.49841)1-5
SECTION 2
Disassembly method
2.1 Main body section
2.1.1 Removing the front panel assembly
(See Fig.1)
(1) Push the detach button in the lower right part of the front
panel assembly.
(2) Remove the front panel assembly in the direction of the ar-
row.
Fig.1
Front panel assembly
Detach button
