KD-SH9101
3-10
Switch board
Block No. [0][2][0][0]
Front board
Block No. [0][3][0][0]
R936 NRSA63D-473X MG RESISTOR 47k
Ω
1/16W D
R937 NRSA63D-392X MG RESISTOR 3.9k
Ω
1/16W D
R939 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R941 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R942 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R943 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R944 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R945 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R946 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R947 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R948 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R949 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R950 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R951 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R952 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R953 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R954 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R961 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R981 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R983 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R984 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R985 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R986 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R987 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R988 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R991 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R992 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R993 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R994 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R995 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
VR931 QVP0033-331Z TRIM RESISTOR 330
Ω
L1 NQL114K-100X COIL 10uH K
L101 NQL114K-470X COIL 47uH K
L102 NQL114K-470X COIL 47uH K
SH91
01E
L701 NQL114K-470X COIL 47uH K
L901 QQR1198-001 CHOKE COIL
L931 NQLZ007-151X COIL 150uH
L941 NQL093K-1R8X COIL 1.8uH K
L942 NQL093K-1R8X COIL 1.8uH K
L981 NQL114K-470X COIL 47uH K
L991 NQL114K-470X COIL 47uH K
BZ961 QAN0023-001Z BUZZER
CN321 QGA2501C1-06 CONNECTOR W-B (1-6)
CN322 QGA2501C1-07 CONNECTOR W-B (1-7)
CN701 QGF0503C1-06V CONNECTOR FFC/FPC (1-6)
CN702 QGA2006C1-02 CONNECTOR W-B (1-2)
CN703 QGF0503F3-07X CONNECTOR FFC/FPC (1-7)
CN901 QNZ0090-001 CAR CONNECTOR
CN941 QNZ0095-001 CONNECTOR
CN981 QGB2027M4-22S CONNECTOR B-B (1-22)
CN982 QGA2501F1-02 CONNECTOR W-B (1-2)
CN991 QGF1034C1-20X CONNECTOR FFC/FPC (1-20)
J1 QAM0105-002 CAR CABLE
PP1 QZW0010-001 STYLE PIN
TU1 QAU0203-002 TUNER
X51 QAX0263-001Z CRYSTAL 4.332MHz
X101 QAX0264-002Z CRYSTAL 22.5792MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
CN804 QGF0503F3-07X CONNECTOR FFC/FPC (1-7)
CN805 QGF1013F1-20X CONNECTOR FFC/FPC (1-20)
CN811 QGZ2202L1-16 CONNECTOR (1-16)
S891 NSW0146-001X DETECT SW
S892 NSW0146-001X DETECT SW
S893 NSW0146-001X DETECT SW
Symbol No.
Part No. Part Name Description Local
S894 NSW0146-001X DETECT SW
S895 NSW0146-001X DETECT SW
S896 NSW0146-001X DETECT SW
Symbol No.
Part No. Part Name Description Local
IC801 MN102H60KCJ1 IC
IC802 IC-PST3424U-X IC
IC803 LH28F160BJHET93 IC
IC804 NJU7241F33-X IC
IC805 RPM6938-SV4 REMOCON RCV
Q801 UN2111-X TRANSISTOR
Q802 2SD601A/QR/-X TRANSISTOR
Q803 2SB709A/QR/-X TRANSISTOR
Q804 2SB709A/QR/-X TRANSISTOR
Q805 2SB709A/QR/-X TRANSISTOR
Q821 UN2211-X TRANSISTOR
Q822 UN2211-X TRANSISTOR
Q823 UN2211-X TRANSISTOR
Q824 UN2211-X TRANSISTOR
Q825 UN2211-X TRANSISTOR
Q826 UN2211-X TRANSISTOR
D801 1SS355-X SI DIODE
D802 1SS355-X SI DIODE
D803 1SS355-X SI DIODE
D804 1SS355-X SI DIODE
D805 1SS355-X SI DIODE
D806 UDZS6.2B-X Z DIODE
D807 UDZS6.2B-X Z DIODE
D808 UDZS6.2B-X Z DIODE
D809 UDZS6.2B-X Z DIODE
D810 UDZS6.2B-X Z DIODE
D811 UDZS6.2B-X Z DIODE
D812 UDZS6.2B-X Z DIODE
D813 UDZS6.2B-X Z DIODE
D814 UDZS6.2B-X Z DIODE
D821 MA152WK-X SI DIODE
D822 SML-310LT/MN/-X LED
D823 SML-310LT/MN/-X LED
D824 SML-310LT/MN/-X LED
D825 SML-310LT/MN/-X LED
D826 SML-310LT/MN/-X LED
D827 SML-310LT/MN/-X LED
D828 SML-310LT/MN/-X LED
D829 SML-310LT/MN/-X LED
D830 SML-310LT/MN/-X LED
D831 SML-310LT/MN/-X LED
D832 SML-310LT/MN/-X LED
D833 SML-310LT/MN/-X LED
D834 SML-310LT/MN/-X LED
D835 SML-310LT/MN/-X LED
D836 SML-310LT/MN/-X LED
D837 SML-310LT/MN/-X LED
D838 SML310BAT/JKL-X LED
D839 SML310BAT/JKL-X LED
D840 NSPW300BS/BRS/ LED WHITE
D841 NSPW300BS/BRS/ LED WHITE
D842 NSPW300BS/BRS/ LED WHITE
C801 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C802 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C803 NDC31HJ-300X C CAPACITOR 30pF 50V J
C804 NDC31HJ-300X C CAPACITOR 30pF 50V J
C805 NDC31HJ-471X C CAPACITOR 470pF 50V J
C806 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C807 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C808 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C809 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C810 NCB31CK-473X C CAPACITOR 0.047uF 16V K
Symbol No.
Part No. Part Name Description Local
