KD-SH9101
3-12
Mecha control board
Block No. [0][4][0][0]
EN801 QSW1025-001 ROTARY ENCODER
R812 NRSA63J-680X MG RESISTOR
SH91
01E
S801 NSW0066-001X TACT SW
S802 NSW0066-001X TACT SW
S803 NSW0066-001X TACT SW
S804 NSW0066-001X TACT SW
S805 NSW0066-001X TACT SW
S806 NSW0066-001X TACT SW
S807 NSW0066-001X TACT SW
S808 NSW0066-001X TACT SW
S809 NSW0066-001X TACT SW
S810 NSW0066-001X TACT SW
S811 NSW0066-001X TACT SW
S812 NSW0066-001X TACT SW
S813 NSW0066-001X TACT SW
S814 NSW0066-001X TACT SW
S815 NSW0066-001X TACT SW
S816 NSW0066-001X TACT SW
S817 NSW0066-001X TACT SW
TH801 NAD0022-103X N THERMISTOR 10k
Ω
10mW F
X801 NAX0586-001X C RESONATOR 25.000MHz
Symbol No.
Part No. Part Name Description Local
IC501 TMP91CW12AF4RA3 IC
IC502 BR24C01AFV-W-X IC
IC503 HD74HCT126T-X IC
IC504 NJU7241F33-X IC
IC571 PCM1716E-X IC
IC572 NJM4565V-X IC
IC601 TA2157FN-X RF AMP IC
IC621 TC94A14FA CD LSI IC
IC651 NJU7241F25-X IC
IC652 TC94A20F-008 IC
IC681 BA5830FP-X IC
Q501 UN2111-X TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q571 UN2111-X TRANSISTOR
Q572 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D501 1SS355-X SI DIODE
D502 1SS355-X SI DIODE
D503 1SS355-X SI DIODE
D504 1SS355-X SI DIODE
D505 1SS355-X SI DIODE
D506 RB160M-30-X SB DIODE
D682 1SR154-400-X DIODE
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 NEAD0JM-107X E CAPACITOR 100uF 6.3V M
C504 NDC31HJ-270X C CAPACITOR 27pF 50V J
C505 NDC31HJ-220X C CAPACITOR 22pF 50V J
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C510 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C512 NEAD0JM-107X E CAPACITOR 100uF 6.3V M
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C514 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C571 NDC31HJ-100X C CAPACITOR 10pF 50V J
C572 NDC31HJ-100X C CAPACITOR 10pF 50V J
C573 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C574 NEAD1CM-106X E CAPACITOR 10uF 16V M
Symbol No.
Part No. Part Name Description Local
C575 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C576 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C577 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C578 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C579 NEAD1CM-106X E CAPACITOR 10uF 16V M
C580 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C581 NCS31HJ-101X C CAPACITOR 100pF 50V J
C582 NCS31HJ-101X C CAPACITOR 100pF 50V J
C583 NCS31HJ-821X C CAPACITOR 820pF 50V J
C584 NCS31HJ-821X C CAPACITOR 820pF 50V J
C585 NEAD1VM-475X E CAPACITOR 4.7uF 35V M
C586 NEAD1VM-475X E CAPACITOR 4.7uF 35V M
C587 NCS31HJ-121X C CAPACITOR 120pF 50V J
C588 NCS31HJ-121X C CAPACITOR 120pF 50V J
C589 NEAD1VM-475X E CAPACITOR 4.7uF 35V M
C590 NEAD1VM-475X E CAPACITOR 4.7uF 35V M
C591 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C592 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C593 NEAD1CM-476X E CAPACITOR 47uF 16V M
C594 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C595 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C596 NCS31HJ-101X C CAPACITOR 100pF 50V J
C597 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C598 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C601 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C602 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C603 NEAD0JM-107X E CAPACITOR 100uF 6.3V M
C604 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C605 NCB31HK-682X C CAPACITOR 6800pF 50V K
C606 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C607 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C608 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C609 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C610 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C611 NCS31HJ-680X C CAPACITOR 68pF 50V J
C612 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C613 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C614 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C616 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C621 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C622 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C623 NCS31HJ-470X C CAPACITOR 47pF 50V J
C624 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C625 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C626 NCB31HK-272X C CAPACITOR 2700pF 50V K
C627 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C628 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C629 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C630 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C631 NCS31HJ-471X C CAPACITOR 470pF 50V J
C632 NCS31HJ-471X C CAPACITOR 470pF 50V J
C633 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C634 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C635 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C636 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C637 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C638 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C639 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C640 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C641 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C642 NCS31HJ-101X C CAPACITOR 100pF 50V J
C643 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C644 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C645 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C646 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C651 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C652 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C653 NEAD0JM-476X E CAPACITOR 47uF 6.3V M
C654 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C658 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C659 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C660 NCS31HJ-101X C CAPACITOR 100pF 50V J
C661 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C662 NCS31HJ-101X C CAPACITOR 100pF 50V J
C663 NCB31CK-104X C CAPACITOR 0.1uF 16V K
