JVC KD-T401 User Manual

12
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
DISPLAY SETTINGS
Zone identification for brightness settings
Zone identification for color settings
1 Press and hold .
2 Press VOL +/– to select an item (page13), then press * ENTER.
3 Repeat step 2 until the desired item is selected/activated or follow the
instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press
.
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page20)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W]* Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[FRQ120HZ] is selected in [SUBWOOFERLPF] and [FRQTHROUGH] is not available.
(Page10)
–
[POSITION R01] is selected in [FADER] and selectable range is [POSITION R06] to
[POSITION 00] . (Page10)
* For KD-T406/KD-T401.
AUDIO SETTINGS
(Symbolic button)
(Symbolic button)
JS_JVC_KD_T408_M_EN_3.indd 12JS_JVC_KD_T408_M_EN_3.indd 12 27/6/2018 12:02:52 PM27/6/2018 12:02:52 PM

JVC KD-T401 Specifications

General

DIN size	1 DIN
CD player	Yes
Output power	200 W
Product color	Black
Ready for iPod	-
High pass filter	No
Disc types supported	CD
Audio output channels	- channels
Equalizer bands quantity	3
Maximum power per channel	50 W
Audio formats supported	FLAC, MP3, WAV, WMA
Display type	LCD
Illumination color	White
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	24
Package weight	1500 g

Weight and Dimensions

Depth	158 mm
Width	182 mm
Height	53 mm
Weight	1200 g
