JVC KD-T402 User Manual

4
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BASICS
To On the faceplate
Turn on the power
Press SRC-B.
• Press and hold to turn off the power.
Adjust the volume Press VOL +/– .
• Press and hold VOL + to continuously increase the volume to 15.
Press * ENTER to mute the sound or pause playback.
• Press again to cancel. The volume level returns to the previous level before muting or pause.
Select a source
• Press SRC-B repeatedly.
• Press SRC-B, then press VOL +/– within 2 seconds.
Change the display information
Press
repeatedly. (Page 15)
Select an item
1 Press VOL +/– to select an item.
2 Press * ENTER to confirm.
Attach
How to reset
Detach
Faceplate
Your preset
adjustment will be
erased except stored
radio stations.
Loading slotSymbolic button
Detach button
Source button
Display window
KD-T401:
JS_JVC_KD_T409_E_EN_01.indd 4JS_JVC_KD_T409_E_EN_01.indd 4 5/30/2018 11:22:15 AM5/30/2018 11:22:15 AM

JVC KD-T402 Specifications

General

DIN size	1 DIN
Equalizer	Yes
Impedance	4 Ω
Output power	350 W
Product color	Black
Ready for iPod	No
Volume control	Rotary
Disc types supported	CD
Audio output channels	- channels
Equalizer bands quantity	15
Maximum power per channel	50 W
Mobile operating systems supported	Android
USB version	2.0
USB ports quantity	1
Audio formats supported	FLAC, MP3, WAV, WMA
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	1500 g

Weight and Dimensions

Depth	158 mm
Width	182 mm
Height	53 mm
Weight	1200 g
