JVC KD-X161 User Manual

10
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Default: [XX]
[EQSETTING]
[PRESET EQ]
Selects a preset equalizer suitable to the music genre.
• Select [USER] to use the settings made in [EASYEQ] or [PROEQ].
[FLAT]/[DRVN3]/[DRVN2]/[DRVN1]/[HARDROCK]/[HIPHOP]/[JAZZ]/
[POP]/[R&B]/[TALK]/[USER]/[VOCALBOOST]/[BASSBOOST]/[CLASSICAL]/
[DANCE]
[EASYEQ]
Adjusts your own sound settings.
• The settings are stored to [USER] in [PRESET EQ].
• The settings made may affect the current settings of [PROEQ].
[SUB.W SP]*1*2: [00] to [+06] (Default: [+03]
[SUB.W]*1*3: [–08] to [+08] [00]
[BASS]: [LVL–06] to [LVL+06] [LVL00]
[MID]: [LVL–06] to [LVL+06] [LVL00]
[TRE]: [LVL–06] to [LVL+06] [LVL00])
[PRO EQ]
Adjusts your own sound settings.
• The settings are stored to [USER] in [PRESET EQ].
• The settings made may affect the current settings of [EASYEQ].
1 [BASS]/[MIDDLE]/[TREBLE]: Select a sound tone.
2 Adjust the sound elements of the selected sound tone.
[BASS] Frequency : [60HZ]/[80HZ]/[100HZ]/[200HZ]
Level : [LVL–06] to [LVL+06]
Q : [Q1.0]/[Q1.25]/[Q1.5]/[Q2.0]
(Default : [80HZ]/[LVL00]/[Q1.0])
[MIDDLE] Frequency : [0.5KHZ]/[1.0KHZ]/[1.5KHZ]/[2.5KHZ]
Level : [LVL–06] to [LVL+06]
Q : [Q0.75]/[Q1.0]/[Q1.25]
(Default : [1.0KHZ]/[LVL00]/[Q1.25])
[TREBLE] Frequency : [10.0KHZ]/[12.5KHZ]/[15.0KHZ]/[17.5KHZ]
Level : [LVL–06] to [LVL+06]
Q : [QFIX]
(Default : [10.0KHZ]/[LVL00]/[QFIX])
[AUDIO CONTROL]
[BASS BOOST]
[LEVEL+01] to [LEVEL+05] ([LEVEL+01]): Selects your preferred bass
boost level. ; [OFF]: Cancels.
[LOUDNESS]
[LEVEL01]/[LEVEL02]: Boosts low or high frequencies to produce a well-
balanced sound at low volume. ; [OFF]: Cancels.
[SUB.W
LEVEL]*1
[SPK-OUT]*2
[SUB.W00] to [SUB.W+06] ([SUB.W+03]): Adjusts the
output level of the subwoofer connected via speaker lead.
(Page 17)
[PRE-OUT]*3
[SUB.W–08] to [SUB.W+08] ([SUB.W00]): Adjusts
the output level of the subwoofer connected to the lineout
terminals (REAR/SW) through an external amplifier.
(Page 17)
[SUBWOOFER
SET]*3
[ON]: Turns on the subwoofer output. ; [OFF]: Cancels.
[SUBWOOFER
LPF]*1
[FRQ THROUGH]: All signals are sent to the subwoofer. ;
[FRQ55HZ]/[FRQ85HZ]/[FRQ120HZ]: Audio signals with frequencies lower
than 55 Hz/85 Hz/120 Hz are sent to the subwoofer.
[SUB.W
PHASE]*1*4
[REVERSE] (180°)/[NORMAL] (0°): Selects the phase of the subwoofer output
to be in line with the speaker output for optimum performance.
[FADER]
[POSITIONR06] to [POSITIONF06] ([POSITION00]): Adjusts the front and
rear speaker output balance.
[BALANCE]*5
[POSITIONL06] to [POSITIONR06] ([POSITION00]): Adjusts the left and
right speaker output balance.
*1, *2, *3, *4, *5: (page 11)
AUDIO SETTINGS
JS_JVC_KD_X161_M_EN_1.indd 10JS_JVC_KD_X161_M_EN_1.indd 10 19/6/2018 8:19:11 AM19/6/2018 8:19:11 AM

JVC KD-X161 Specifications

General

DIN size	1 DIN
Impedance	4 Ω
Output power	200 W
Product color	Black
Ready for iPod	-
Volume control	Rotary
Low pass filter	Yes
Disc types supported	No
Audio output channels	- channels
Maximum power per channel	50 W
Package width	900 mm
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
Headphone connectivity	3.5mm
Display type	LCD
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, FRE, RUS

Weight and Dimensions

Depth	53 mm
Width	182 mm
Height	100 mm
Weight	600 g
