[VOLUME ADJUST] [LEVEL–15] to [LEVEL+06] ([LEVEL 00]): Presets the initial volume
level of each source by comparing to the FM volume level. (Before
adjustment, select the source you want to adjust. “VOL ADJ FIX” appears
if FM is selected.)
[AMPGAIN]
[LOWPOWER]: Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50 W to prevent damaging
the speakers.) ; [HIGHPOWER]: The maximum volume level is 35.
[D.T.EXPANDER]
(Digital Track
Expander)
[ON]: Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression. ; [OFF]: Cancels.
[SPK/PREOUT] Depending on the speaker connection method, select the appropriate
setting for the desired output. (See “Speaker output settings”.)
*1 Displayed only when [SUBWOOFER SET] is set to [ON]. (Page 10)
*2 Displayed only when [SPK/PREOUT] is set to [SUB.W/SUB.W].
*3 Selectable only if a setting other than [FRQTHROUGH] is selected for [SUBWOOFERLPF].
(Page 10)
*4 This adjustment will not affect the subwoofer output.
AUDIO SETTINGS
Speaker output settings [SPK/PRE OUT]
Select the output setting for the speakers [SPK/PRE OUT] , based on the speaker
connection method.
Connection via lineout terminals
For connections through an external amplifier. (Page17)
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
[REAR/REAR] (default) Front speakers
output
Rear speakers output Subwoofer output
[SUB.W/SUB.W] Front speakers
output
L (left): Subwoofer output
R (right): (Mute)
Subwoofer output
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page17)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[FRQ120HZ] is selected in [SUBWOOFERLPF] and [FRQTHROUGH] is not available.
(Page10)
–
[POSITION R01] is selected in [FADER] and selectable range is [POSITION R06] to
[POSITION 00] . (Page10)
