JVC KD-X282DBT User Manual

16
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Bluetooth® (for KD-X282DBT)
Improve the voice quality
While talking on the phone...
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2 until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press
.
Default: [XX]
[MIC GAIN] [LEVEL –10] to [LEVEL +10] ([LEVEL –04]): The sensitivity of the
microphone increases as the number increases.
[NR LEVEL]
[LEVEL –05] to [LEVEL +05] ([LEVEL 00]): Adjust the noise reduction level
until the least noise is being heard during a phone conversation.
[ECHO CANCEL]
[LEVEL –05] to [LEVEL +05] ([LEVEL 00]): Adjust the echo cancellation
delay time until the least echo is being heard during a phone conversation.
• Call quality may depend on mobile phone.
Make the settings for receiving a call
1
Press to enter Bluetooth mode.
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2 until the desired item is selected or activated.
To return to the previous setting item, press
.
Default: [XX]
[SETTINGS]
[AUTO ANSWER]
[01SEC] to [30SEC]: Answers an incoming call automatically in the selected
time (in seconds). ; [OFF]: Cancels.
[RING ILLUMI]
[BLINK01] to [BLINK05] ([BLINK02]): Selects the blinking pattern for the
buttons as notification when there is an incoming call. ; [OFF]: Cancels.
Make a call
You can make a call from the call history, phonebook, or dialing the number.
Call by voice is also possible if your mobile phone has the feature.
1 Press to enter Bluetooth mode.
“(First device name)” appears.
• If two Bluetooth phones are connected, press again to switch
to the other phone.
“(Second device name)” appears.
2 Turn the volume knob to select an item (page17), then press the
knob.
3 Repeat step 2 until the desired item is selected/activated or follow the
instructions stated on the selected item.
To return to the previous setting item, press
.
KD-X282DBT_E_B5A-3845-00_EN_1st Draft.indd 16KD-X282DBT_E_B5A-3845-00_EN_1st Draft.indd 16 7/9/2021 4:26:58 PM7/9/2021 4:26:58 PM

JVC KD-X282DBT Specifications

General

DIN size	1 DIN
Impedance	75 Ω
Output power	200 W
Product color	Black
Volume control	Rotary
Frequency range	531 - 1611 Hz
Disc types supported	-
Audio output channels	7.1 channels
Maximum power per channel	50 W
Signal-to-Noise Ratio (SNR)	6.2 dB
Mobile operating systems supported	Yes
CD-R playback	No
Audio formats supported	FLAC, MP3, WAV, WMA
Display type	LCD
Illumination color	Red, White
Bluetooth version	4.2
USB port position	Front
Bluetooth profiles	AVRCP
USB connector type	USB Type-A
USB ports quantity	1
Bluetooth functions	Audiostreaming, Handsfree calling
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
FM usable sensitivity	6.2
Supported radio bands	DAB, FM, LW, MW
Preset stations quantity	42
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	60 g
