Crossover settings

Below are the available setting items for 2-way crossover and 3-way

crossover.

CAUTION

Select a crossover type according to how the speakers are connected.

(Page33)

If you select a wrong type:

• The speakers may be damaged.

• The output sound level may be extremely high or low.

SPEAKER SIZE

Selects according to the connected speaker size for optimum performance.

• The frequency and slope settings are automatically set for the crossover of

the selected speaker.

• If

[NONE]

is selected for the following speaker in

[SPEAKER SIZE]

, the

[X ‘ OVER]

setting of the selected speaker is not available.

– 2-way crossover:

[TWEETER]

[FRONT]

[REAR]

[SUBWOOFER]

– 3-way crossover:

[WOOFER]

X ‘ OVER (crossover)

•

[FRQ]

[F-HPFFRQ]

[R-HPFFRQ]

[SWLPF FRQ]

[HPFFRQ]

[LPFFRQ]

: Adjusts the

crossover frequency for the selected speakers (high pass filter or low pass

filter).

[THROUGH]

is selected, all signals are sent to the selected speakers.

•

[SLOPE]

[F-HPFSLOPE]

[R-HPFSLOPE]

[SWLPF SLOPE]

[HPFSLOPE]

[LPFSLOPE]

Adjusts the crossover slope.

Selectable only if a setting other than

[THROUGH]

is selected for the

crossover frequency.

•

[SW LPF PHASE]

[PHASE]

: Selects the phase of the speaker output to be in line

with the other speaker output.

•

[GAINLEFT]

[GAINRIGHT]

[F-HPFGAIN]

[R-HPFGAIN]

[SWLPF GAIN]

[GAIN]

: Adjusts

the output volume of the selected speaker.

Audio Settings

2-way crossover setting items

[SPEAKER SIZE]

[FRONT] [SIZE]

[8CM]/[10CM]/[12CM]/[13CM]/[16CM]/

[17CM]/[18CM]/[4×6]/[5×7]/[6×8]/[6×9]/

[7×10]

[TWEETER]

[SMALL]/[MIDDLE]/[LARGE]/[NONE] (not

connected)

[REAR]*1

[8CM]/[10CM]/[12CM]/[13CM]/[16CM]/[17CM]/[18CM]/[4×6]/

[5×7]/[6×8]/[6×9]/[7×10]/[NONE] (not connected)

[SUBWOOFER]*2*3

[16CM]/[20CM]/[25CM]/[30CM]/[38CM OVER]/[NONE] (not

connected)

[X ' OVER]

[TWEETER] [FRQ]

[1KHZ]/[1.6KHZ]/[2.5KHZ]/[4KHZ]/[5KHZ]/

[6.3KHZ]/[8KHZ]/[10KHZ]/[12.5KHZ]

[GAIN LEFT]

[–08DB] to [00DB]

[GAIN RIGHT]

[–08DB] to [00DB]

[FRONT HPF] [F-HPF FRQ]

[30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/

[90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/

[220HZ]/[250HZ]/[THROUGH]

[F-HPF SLOPE]

[–06DB]/[–12DB]/[–18DB]/[–24DB]

[F-HPF GAIN]

[–08DB] to [00DB]

[REAR HPF]*1 [R-HPF FRQ]

[30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/

[90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/

[220HZ]/[250HZ]/[THROUGH]

[R-HPF SLOPE]

[–06DB]/[–12DB]/[–18DB]/[–24DB]

[R-HPF GAIN]

[–08DB] to [00DB]

*1, *2, *3: (see page 25)
