AUDIO SETTINGS
Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
Caution
Select a crossover type according to how the speakers are connected.
(  33 )
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or low.
SPK SIZE (speaker size)
Selects according to the connected speaker size for optimum
performance.
• The frequency and slope settings are automatically set for the
crossover of the selected speaker.
• If [ NONE ] is selected for [ TWEETER ] of [ FRONT ], [ REAR ] and [ SUBWOOFER ] for
[
SPK SIZE ], the [ X ‘ OVER ] setting of the selected speaker is not available.
X ‘ OVER (crossover)
[ FRQ ]/ [ HPFFRQ ]/ [ LPFFRQ ]:
Adjusts the crossover frequency for the selected speakers (high pass
filter or low pass filter).
• If [ THROUGH ] is selected, all signals are sent to the selected speakers.
[ SLOPE ]/ [ HPFSLOPE ]/ [ LPFSLOPE ] :
Adjusts the crossover slope.
• Selectable only if a setting other than [ THROUGH ] is selected for the
crossover frequency.
[PHASE]:
Selects the phase of the speaker output to be in line with the other
speaker output.
[ GAINLEFT ]/ [ GAINRIGHT ]/ [ GAIN ]:
Adjusts the output volume of the selected speaker.
(For KD-X33MBS )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
REAR/REAR
(default)
Front speakers
output
Rear speakers output Subwoofer output
REAR/SUB.W ( Not available ) ( Not available ) ( Not available )
SUB.W/SUB.W Front speakers
output
L (left): Subwoofer output
R (right): (Mute)
Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output.
(  33 )
Setting on
[ SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [ SUB.W/SUB.W ] is selected:
– [
FRQ120HZ ] is selected in [ SUB.W  LPF ] and [ THROUGH ] is not available.
– [
R02 ] is selected in [ FADER ] and selectable range is [ R15 ]to [ 00 ].
